DIY CNC 3018 X Metal Frame CNC 3018 Upgrade Kit Spindle Hole Diameter 52mm
Can be shipped from Russian warehouse
Foot pads installed at four corners of the machine
Screws are equipped with gaskets to protect the machine more
Both screws are equipped with knobs, size 8mm
Horizontal screw seat, inner diameter 8
Full metal oxidation sandblasting
12mm optical axis, stable and durable
Z axis can be raised and lowered as a whole
PS: Equipped with baffle and emergency stop switch hole
XYZ three-axis actual stroke 300*180*60mm
Aluminum Table Size 300*180mm
Material: Aluminium
Stepper motor: Apply to Nema48/57 Stepper
Screw: T8 stainless steel screw, lead 8MM, POM anti-backlash nut
Spindle hole diameter: 52mm
Packing list 1:1*CNC 3018Plus Metal Frame
Packing list 2:1*CNC 3018Plus Metal Frame+3 * Nema17 42HS48mm
This kit is disassemble, needs the customer DIY assembling, needs certain electronic and the Mechanical Foundation.
Packing List 1:
Packing list 2:
