Mini CNC Router 3020 USB Metal Engraving Milling Cutting Machine 300W 500W 800W CNC Engraver Cutter GRBL MACH3 Optional 110/220V
Machine Parameter | ||||
Model | CNC 3020 | |||
Effect stroke | 200*300*60mm(X/Y/Z) | |||
Machine size | 510*450*460mm | |||
Acceptable material thickness | Max 80mm | |||
Table size | 300*440mm | |||
Rack material | 6061-T6 aluminum alloy(15mm) | |||
Transmission | 1605 Ball screw | |||
Guide liner rail type | Round rod(X:16/Y16/Z12) | |||
Electronic control | ||||
Model | 300W | 500W | 800W | |
Spindle power | DC 300W | DC 500W | DC 800W | |
Spindle driver | DC governor | DC governor | DC governor | |
Spindle speed | 0~12000rpm/min | 0~12000rpm/min | 0~24000rpm/min | |
Cooling way | Air cooling | Air cooling | Water | |
Collet type | ER-3.175/4 | ER-3.175/4 | ER-3.175/4 | |
Stepper motor | 57BYGH56 | 57BYGH56 | 57BYGH56 | |
Stepper driver | 16 segments -4A | 16 segments -4A | 16 segments -4A | |
Repeat positioning Accuracy | ±0.03mm | ±0.03mm | ±0.03mm | |
Precision | ±0.05mm | ±0.05mm | ±0.05mm | |
Software | GRBL/MACH3 | GRBL/MACH3 | GRBL/MACH3 | |
Communication interface | USB port | USB port | USB port | |
Input voltage | AC220V/AC110V | AC220V/AC110V | AC220V/AC110V | |
Command code | G-code(.nc,gcode,.tap) | G-code(.nc,gcode,.tap) | G-code(.nc,gcode,.tap) | |
Software Copatability | AutoCAD,CDR,UG,ArtCAM,PowerMill | AutoCAD,CDR,UG,ArtCAM,PowerMill | AutoCAD,CDR,UG,ArtCAM,PowerMill |
