Noting:
1: PC Support : Windows XP/7/8/10 system
2: For USB output, the white balance, exposure and color adjustment are automatic, they can't be adjusted. For HDMI output, the functions can only be adjusted while connecting with monitor, if you connect the camera with computer, the functions also can not be adjusted.
3: When use USB connection, please make sure no TF card in the camera ,TF card storage is only for HDMI output. USB output will be storage in PC.
4: When connect the camera with computer, just plug the USB line is OK ( no need to use the power supply)
Features:
Sensor: SONY IMX334
Real-time output resolution: 4K/2K/1080P
Sensor Size: 1/1.8 inch
Pixel Size: 2.0 x 2.0 μm
Image Resolution: 8528 x 4808 (41 MegaPixel)
Frame rate: 3840 x 2160 @30FPS(4K); 1080P @60FPS
Image Format: JPEG
Wave Length[nm]: 400nm~1000nm
Lens Type: C/CS Mount
Storage: TF Card, Maximum support 256G (TF card is not included)
PC Support:Windows / Mac / Linux, PC Software with Measuring Function
Image Measurement: Support HAYEAR Measurement
Language: Chinese, English, Japanese, French, German, Russian, Italian, Korean, Turkish
Output Interface: HDMI / USB Type-C 3.0 interface
HDR Function: Support HDR,Multiple exposure HDR, Digital overlap HDR
Video output interface: HDMI/USB dual interface can output image simultaneously
Timer function: Support taking pictures/video recording at specified time
Comparison on the same screen: Real-time observation and comparison of two products
White Balance: Support One-click, Auto and Manual white balance
Image Zoom: 7x digital zoom
Transverse and vertical line: Support multi-color, 5 pcs of transverse lines/vertical lines, movable Different color,5 horizontal line, 5 vertical line, any positions
Exposure: Auto/Manual, value adjustable
Encode: H.264 /H.265 (High Profile)
Video format: Video format
Input Voltage: Type-C 5V / DC 12V 1A
Size: 45×45×53mm
180X C-MOUNT Lens
Working distance: 95mm
Zoom c-mount Lens
0.5X C-mount adapter
Zoom ratios: 6.5:1
Objective Magnification Power by 0.7 - 4.5X(about 10 - 180X on the display)
Size: 180mm(L) * 50mm(DIA)
Working distance:145-100mm
300X C-MOUNT Lens
Working distance: 95mm
Zoom c-mount Lens
1X C-mount adapter
Zoom ratios: 6.5:1
Objective Magnification Power by 0.7 - 4.5X(about 10 - 300X on the display)
Size: 248mm(L) * 50mm(DIA)
Working distance:110-100mm
100X C-MOUNT Lens
Magnification Power by 0.12 - 2X (about 8X - 100X on the display)
Work distance: 100mm
Visual field :2.4mm-32mm
Size: 115mm(L) * 40mm(DIA)
Weight: 210g
Working distance:30-280mm
130X C-MOUNT Lens
Zoom ratio: 15: 1
Magnification Power by :1X~120X
Material vision: 2.4mm-36mm
Working distance: 55mm-570mm
Lens length: 110mm
Interface size: ¢ 28mm
200X Working distance:100mm -175mm
500X Working distance:90mm -110mm
Connector:CS C mount
Zoom:continouasly variable zoom
Objective Magnification:0.7X - 5X(about 28 - 200X on the display)/(about 70 - 500X on the display)
Eyepiece lens adapter:0.4X/1X
Fixed position:50mm
Locking:0.7X - 5X Locking
Thread:42mm
Auxiliary Objective Lens:0.35X, 0.5X, 2X,1X (optional)
Size:132mm(L) * 55mm(DIA) / 175mm(L) * 55mm(DIA)
56 LED Adjustable Compact Microscope Ring Light
Provides intense and focused shadow-free illumination
56 bright white LED bulbs
Lighting direction changeable
Variable intensity control
Intense and focused shadow-free illumination
100,000 hours of life
Power input: 100-240V, 50-60HZ, auto switching
Inside diameter of the ring light: 1.0" (27mm)
Overall outside diameter: 1.77" (45mm)
Working Distance: 27mm-120mm
Package including:
1 x 4K Microscope Camera
1 x Power supply
1 x USB line
1 x HDMI line
1 x Remote Control
Optional Accessories Incluede:
1 x C-MOUNT Lens(100X or 180X or 300X or 130X or 200X or 500X)
1 x 56 LED Adjustable Microscope Ring Light
