[Upgraded Version IMPROVED FREQUENCY ALGORITHM] Measurement range 100KHz-6GHz (previous vna analyzers are around 10KHz-3GHz), Above 3GHz, the performance decreases with increasing frequency, and the port isolation is only 50dB at 6GHz. Below 1MHz, the performance decreases with decreasing frequency, and the effective dynamic decreases to 70dB at 100kHz
[Full S-Parameters Measurements] In the Vector network analyzer operating mode, the VNA takes all 4 S-Parameters measurements. A source signal is generated and alternately applied to the RF ports. This incoming signal at both RF ports is measured, resulting in the four S-parameters S11&S21(when signal routes to Port 1), as well as S12&S22(when signal routes to Port 2)
[3 In 1 Device] Although the VNA hardware is not designed to be used as spectrum analyzer and signal generator, the general hardware architecture of a spectrum analyzer and signal generator are similar enough to that of a VNA to implement basic spectrum measurements and output a CW signal, which might suffice if no other equipment is available. The main differences to a real spectrum analyzer and signal generator please refer to the product description
[USB Based Full Dual-port Measurements] Using 3 ADCs to sample data simultaneously and using FPGAs for signal processing, Libre VNA handheld antenna Analyzer is capable of scanning over 10,000 points of full dual-port measurements in less than 1 second
Colour:silver
Material:Metal
Package Contents:
1 set * vector network analyzer
Only the above package content, other products are not included.
Note: Light shooting and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
|
