New New Litevna-64 50Khz-6.3Ghz Litevna 4Inch Touch Screen Vector Network Analyzer HF UHF Antenna Analyzer Update Of Nanovna
In order to reduce power consumption and volume, LiteVNA uses only one mixer, through the internal RF switch, can perform S11, S21 measurement, and can perform TDR and DTF measurement after IFFT calculation.
In addition to a wider measurement range, LiteVNA also has faster scanning speed and more scanning points. The operation interface consistent with NanoVNA makes it easy to use LiteVNA as a tool for field testing.
LiteVNA has a Micro-SD slot, you can save the field test data or screen to the Micro-SD card at any time
The 6.3GHz measurement range, in addition to meeting common amateur radio and Internet of Things applications, can also handle 5GHz testing, 5.8GHz wifi and 5.8GHz image transmission.
Colour: Black
Material: Metal+Plastic
Package Contents:
1 x LiteVNA-64 analyzer
1 x USB Type-C data cable
2 x 30cm SMA male to male SS405 RF cable
1 x SMA male calibration kit - OPEN
1 x SMA male calibration kit - SHORT
1 x SMA male calibration kit - LOAD
1 x SMA female to female connector
Only the above package content, other products are not included.
Note: Light shooting and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
