Product Parameters
Whole machine:
Model: 853AAA+
Power: 1200W
Volatage: AC 220-240V,50Hz/ AC 110V,60Hz
Weight: 5.6KG
Preheating part
Temperature range: 50°C-400°C
Display form: LED
Area of preheate plate: 120*120MM
Temperature stablity:±2°C
Hot air gun part
Air flow type: brushless fan with soft wind
Max Air flow：120L/min
Temperature range:100°C-480°C
Display form: LED
Temperature stablity:±1°C
Handle length:≥100CM
Soldering iron part
Temperature range: 200°C-480°C
Display form: LED
Temperature stablity:±1°C
Handle length:≥100CM
Soldering iron tip over the ground resistance: <2ohm
Soldering iron tip over the ground voltage: <2mV
1. Programming desoldering
a step: open the power button of Preheating plate + hot air gun + program
b step: set the working time/temperature/ air flow of preheating and hot air gun
c step: click the START/STOP button., proramming desoldering start, will preheat firtly, and then hot air gun work
2.℃ & °F temperature mode
3.Temperature correction
4.CH1/CH2/CH3 3 Preset storage
5.Working time character
6.fixed 10 mins sleep time of soldering iron
Using
1. Suitable for a variety of original welding, such as: SOIC, CHIP, QFP, PLCC,
BGA and so on
2. It is suitable for heat shrinkage, drying, removing paint, adhesive removal,
thawing, preheating, disinfection, glue welding and so on.
853AAA+ Package Content
1x Soldering station
1x IC extractor
1x Air gun heating element
1x Soldering iron heating element
1x Tubular soldering wire( 1.0mm15g)
2x Tweezers
4x Nozzles
