2000T-3 three axis lathe numerical control system

The company is specialized for the domestic small and medium-sized machine tool manufacturers independent research and development of cost-effective numerical control system.

Using high-performance ARM CPU and large scale programmable device FPGA, real-time multi-task control and hardware interpolation technology, ensure the high efficiency of μm precision machining system.

8 inch color display screen, English and Chinese interface can be selected by parameter.

The 2000T-3 system can control 3 feed axes (including C axis), 2 simulation spindles, 1ms high speed interpolation, 1μm control accuracy, significantly improve the efficiency of parts processing, precision and surface quality.

3000T-3 three axis lathe numerical control system

The company is specialized for the domestic small and medium-sized machine tool manufacturers independent research and development of cost-effective numerical control system.

Using high-performance ARM CPU and large scale programmable device FPGA, real-time multi-task control and hardware interpolation technology, ensure the high efficiency of μm precision machining system.

10.4 inch color display, English and Chinese interface can be selected by parameter.

3000T-3 system can control 3 feed axes (including C axis), 2 simulation spindles, 1ms high speed interpolation, 1μm control accuracy, significantly improve the efficiency of parts processing, precision and surface quality.

2000M-3 three axis milling machine numerical control system

The CNC system of the milling machine machining center is a popular CNC system independently developed by the company, which is suitable for milling machines, drilling and milling machines, grinding machines, etc.

The system uses 32-bit high performance CPU and large scale programmable device FPGA, real-time control and hardware interpolation technology to ensure the high efficiency of the system under the μm level accuracy, and the editable PLC makes the logic control function more flexible and powerful.

8 inch color display screen, 800×480 resolution, English and Chinese interface can be selected by parameter.

2000M-3 system can control 3 feed shafts, 2 simulation spindles, 1ms high-speed interpolation, 0.1μm control accuracy, significantly improve the efficiency of parts processing, precision and surface quality.

3000M-3 three axis milling machine numerical control system

The CNC system of the milling machine machining center is a popular CNC system independently developed by the company, which is suitable for milling machines, drilling and milling machines, grinding machines, etc.

The system uses 32-bit high performance CPU and large scale programmable device FPGA, real-time control and hardware interpolation technology to ensure the high efficiency of the system under the μm level accuracy, and the editable PLC makes the logic control function more flexible and powerful.

10.4-inch color display, 800×600 resolution, English and Chinese interface can be selected by parameter.

3000M-3 system can control 3 feed shafts, 2 simulation spindles, 1ms high-speed interpolation, 0.1μm control accuracy, significantly improve the efficiency of parts processing, precision and surface quality.

Number of control Axis

Number of control axes: 2 Axis ( X, Z )

Number of linkage axles: 2 Axis

Feed axis function

Minimum input increment: 0.001mm (0.0001inch) or 0.0001mm (0.00001inch) Optional

Minimum instruction increment: 0.001mm (0.0001inch) or 0.0001mm (0.00001inch) Optional

Large stroke: ±99999999 x minimum instruction increment

Fast moving speed: maximum 60m/min

Rapid rate: F0, 25%, 50%, 100% four levels of real-time adjustment

Feed rate: 0 ~ 150%, a total of 16 levels of real-time adjustment

Interpolation methods: linear interpolation, arc interpolation (support three-point arc interpolation), thread interpolation, rigid tapping

Automatic chamfering function

Thread function

Normal thread (follow spindle)/ rigid thread

Single head/long head male inch straight thread, taper thread and end thread, equal pitch thread and variable pitch thread

The length, Angle and speed characteristics of thread withdrawal can be set

Thread pitch: 0.01mm to 500mm or 0.06 teeth/inch to 2540 teeth/inch

Acceleration and deceleration function

Cutting feed: front acceleration and deceleration linear, front acceleration and deceleration S type, rear acceleration and deceleration linear, rear acceleration and deceleration exponential type

Fast moving: front acceleration and deceleration linear, front acceleration and deceleration S, rear acceleration and deceleration linear, rear acceleration and deceleration exponential

Thread cutting: linear, exponential optional

The start speed, end speed and time of acceleration and deceleration are set by parameters

Spindle function

2 channels of 0 ~ 10 V analog voltage output, supporting dual spindle control

Spindle encoder: the number of encoder lines can be set (100 p/r ~ 5000 p/r)

Transmission ratio between encoder and spindle: (1 ~ 255): (1 ~ 255)

Spindle speed: can be given by S code or PLC signal, speed range 0r/min ~ 9999r/min

Spindle magnification: 50% ~ 120%, a total of 8 levels of real-time repair and adjustment

Constant linear speed control of main shaft

Tapping cycle, rigid tapping

Tool function

Tool length compensation

Tool tip radius compensation (Type C)

Tool wear compensation

Tool life management

Knife setting method: fixed point knife setting, trial cutting knife setting, back reference point knife setting, automatic knife setting

Tool deviation execution mode: modify coordinate mode, tool movement mode

Accuracy compensation

Pitch error compensation: the number of compensation points, compensation interval and compensation origin can be set

Reverse clearance compensation: it can be set to compensate the reverse clearance of the machine tool in the way of fixed frequency or lifting speed

PLC functions

Two level PLC program with processing speed of 1.5 μ S/ step basic instruction; 4700 steps at most, 8 ms for level 1 program cycle

support PLC warning and PLC alarm

support multiple PLC programs (up to 20), and the currently running PLC programs can be selected

Number of instructions: 45 (including 10 basic instructions and 35 functional instructions)

i/o unit input / output: 36/36

interface

8.4 inch widescreen LCD with a resolution of 800 × 480

Display in Chinese, English and other languages

2D tool path display

Real time clock

Operation management

Operation mode: edit, automatic, input, machine tool zero return, Hand wheel / single step,

manual, DNC

Multi level operation authority management

Alarm log

Program editing

Program capacity: 56 MB, can store up to 400 programs

(including subroutines and macro programs)

Editing function: program / program segment / word retrieval, modification, deletion,

copy and paste

Program format: ISO code, support statement macro code programming, support relative coordinates, absolute coordinates, polar coordinates programming

Program call: support macro program call with parameters and 4-level subroutine nesting

Communication function

RS232: bidirectional transmission of part programs, parameters and other files, supporting PLC program and system software serial port upgrade

USB: U-disk file operation, direct processing of U-disk files, support PLC program and system software U-disk upgrade

Support serial port DNC processing function and USB online processing function

Reliability and safety

function

Emergency stop

Hardware travel limit

Software travel check

Data backup and recovery
