2200W/2.2kw Square 2.2kw Air Cooled Spindle Motor 220V 380V 2.2kw ER20 CNC Spindle Motor for CNC Milling Machine
Package Includes:
1X 2.2KW Spindle Motor
Technical Parameters：
Type: Air interface:
Power: 2.2kw
Voltage: 220V/380V
Current: 6.8A
Frequency: 400Hz
Collet: ER20
Lubrication method: grease lubrication
Cooling method: Air cooling
Type：Junction box
Power: 2.2 KW
Voltage: 220 V/380V
Current: 6A
Frequency: 400 HZ
Runout off: less than 0.01 mm
Precision taper bore: less than 0.005 mm
Rotating speed: 0-24000 rpm
Cooling method: Air cooling
Features：
Strong torque power, a greater degree of friction reduction, improve work efficiency
.
Adopt high precision chuck nut,which has high rotation accuracy
.
The new and upgraded enclosure which is made of high quality stainless steel, smooth and resistant to rust,thickened material, pure copper coil, air cooling heat dissipation, make the motor more durable
.
Low noise, only about 30 decibels when working. better heat dissipation effect, which effectively improves the stable and smooth operation
.
Wiring:The spindle’s terminal"U1"connects inverter’s"U"; Spindle’s terminal "V1"connects inverter’s"V"; Spindle’s terminal "W1" connects inverter’s "W"
.
Main Application: Wood, Glass, PVC industry.
Note：
Please mote that the spindle moor speed can't be lower than 9000rpm (Because it is a high-speed spindle woodworking motor, if the speed is too low, it is easy to damage the spindle motor)
