Weihong Card CNC Control card 3 axis PCIMC-95A, Ncstudio PM95A -3A Lambda3S motion control system Instead of PM53C/3L
This model have Two type: The MPG port Could use and The MPG port could not use.
It could use for Stepper and servo systerm.
It is instead of PM53C Controller / Lambda3L 3 axis CNC Machine controller
CNC SpecificationNumber of Axes Supported: 3 axes Control SignalsPlus Frequency:1MHZControl Mode: Position controlControl Signal: Differential signalsPosition Signal Type: Plus+Direction CommunicationExternal: PCI-EInteractive with Lambda: PHOENIX bus SpindleAnalog Voltage Output: 0-10V Tool MeasurementTool Measurement Mode : Fixed calibration, Mobile calibration, First calibration & Calibration after tool change CompensationCompensation Type: Screw error compensation, Backlash compensation, AQE compensation, Tool compensation Toolpath FileSupported File Format: *.g/*.nc/*.u??/*.demo/*.iso/*.eng/*.cut/*.dxf/*.plt/*.txt OperationsWCS: Supporting WCS G54-G59 and Work Zero savingProcessing Technology: Array, Mirror&rotate, Cycle machining Convenient Operation: Handwheel guide, Breakpoint resume, Tool selection High-speed High-precision OptimizationInterpolation Algorithms: T-type, S-type and LEP algorithms Software Language: Chinese,English Safety & ReliabilitySofeware Alarms: Alarms of program error, operation error, over-travel error, PLC error, and IO communication error
