product content:
Control handle*1
Patch panel*1
Signal line*1
U disk *1
Introduction:
DM500 is very professional 4 Axis CNC Motion Controller which is based on embedded system.DM500
operates as a standalone system without the need of a computer,and with a pendant,it makes users very conve
nient to opreate the machines.Our controller adopts Embedded Operating System,by which the controller will
never get virus-infected.And the controller adopts look-ahead algorithm by which the the controller can read
more ahead 30-lines G-code than the operating.All the features guarantees high precision,accuracy and reliabili
ty.And the size is very small,oepreation is very easy,very suitable for all size of Engraving machines,Milling
machines and cutting machines and so on.
Features:
1) Max. 4 Axis;2-4 Axis linear interpolation,any 2 axis circular interpolation;
2) 7 opto isolated digital outputs,8 opto isolated digital inputs;
3) Support every Input and output port definition by users.
4) The controller need 2 power supply,one power supply is for system power,one is for input and output
ports power.Both input power is 24V,2A.
5) Open-collector output, Max. output current is 500mA,can power the relay directly;
6) Differential Pulse and direction output signal,Max. 500Khz per axis;
7) Spindle Control: 3 I/O ports control 8 different speeds(3 lines 8 speeds),1 I/O control the Start/Stop;
8) The System Support standard G-code.Also Support the popular CAD/CAM software,such as ArtCam,-
MasterCam,ProE and so on.
9) USB flash disk support for G code file input;
10) The control system can preview the process path before machining,and it makes the system more
steady,working smoothy and precise;
11) Acceleration/Deceleration Mode: S curve;
12) Support un-limited size file for machining;
13) Manual/Automatic machining function;
14) Support the operation to Start a G code from a specific line;
15) Support for “Power Cut” recovery. Data is automatically saved;
16) Support time-lock function;
17) Support 4 kinds operation rights:visitor,operator,admin,super admin;
Appearance, Structure and Size of Product：
The DM500 motion controller contains the handheld motion controller,circuit switching wiring board,and
HDMI digital high-definition transmission cable.
The handheld motion controller and wiring board are communicated by 2 Meter 37 pins HDMI digital
high-definition transmission cable which is shielding twisted-pair cable to avoid interference.
The wiring board can be installed by DIN linearguide ways No. C45.
