1.1 The system
F2100B CNC system is in the company to absorb the advantages of many domestic and international CNC system, combined with the company F2100, F2200 and F2300, F3100, F5100 series CNC system, developed a more humane, more convenient, more cost-effective products. The product uses two axis digital position control mode, suitable for oxygen gas and plasma cutter processing industry. For two axis NC machine in all with position control method.
The control system is light and portable, simple operation, easy to use, all the operation has a menu or graphical clues, operate a fool. Humanization design all the key switch, comfortable and convenient.
By the special motor control chip DSP core control system, DSP control the motor so that the cutting process is more stable and reliable. DSP motion control algorithm for the optimization and upgrade in the original F2200, to make the machine run more smoothly and reliably, prolong the life of electrical and mechanical parts.
1.2 system features
Chinese / English menu system, Chinese English French Russian interface of one key switching.
45 kinds of commonly used graphics library (including the grid graphics), can choose the set piece size and pore size.
Supports EIA code (G code) and FastCAM, FreeNest, IBE, Wentai, PM2000 and other kinds of nesting software
Compact keyboard type design, make more comprehensive manual input file
Graphic proportion, rotation, mirror
Graphics can be arranged in a matrix arrangement, interaction, stacked arrangement
Workpiece with slotted size of original size and at the same time display, intuitive and convenient
Graphic plate correction, arbitrary edges of plate can be used as a correction boundary
Can customize the types of all input and output ports (normally closed or open) and number
Self diagnostic system for all IO and key state, convenient examination and troubleshooting
The pre U disk interface for convenient program transmission
Using U disk upgrade system, which is convenient and simple, practical, lifetime free upgrades
All functions can be upgraded online as a whole.
Can import and export single or all processing files
Backup or restore parameters
Supporting oxygen gas, plasma, dusting and demonstrates modes
All kinds of machining parameters is complete, which can meet different process requirements
Oxygen gas and plasma IO separate control
Oxygen gas automatic height adjustment, two stage preheating, three level perforation
Plasma arc voltage feedback, position feedback, automatic closing high pressure arc angle
Control supports the speed and distance of two shut down arc voltage mode l plasma arc pressure, make the machine more balanced, safe
Supports edge-cutting, the preheating time can be reduced for thick steel board
Acceleration, deceleration of speed during the motion.
According to the thickness of the steel plate, speed will be automatically controlled in the corner, effectively preventing over-burning.
Manually select the start line or wear a hole.
Dynamic / static processing graphics, graphics zoom in / out, dynamic tracking cutting point under magnification
DSP high speed, high precision interpolation control, high-speed operation, smooth running, low noise
Set the start speed, acceleration and deceleration time with content
Power off protection, breakpoint memory protection
"offset cutting" function can avoid calculation errors, saving the materials.
Management authority and the corresponding password can be set to maintain management rights
Remote control of before and after, left, right and cutting movement, as well as start and stop function.
Can be used for advertising plasma cutting machine,
Walking frame function,
Choice of the starting point.
1.3 Technical Indicators
1) Axis: 2 (can be customized for three axis)
2) Control precision: ± 0.001mm
3) Coordinate range: 99999.99mm
4) The maximum pulse frequency: 200KHz; maximum speed: 15 m / min.
5) Maximum program line number: 150000
6) Largest single program: 6M
7) Time resolution: 10ms
8) Power supply: DC +24V DC power input
9)System working environment: temperature -10 degree celsius to +60 degree celsius; relative humidity 0-95% no condensation
1.4 System interface
A) 15 core male two motor drive interface
B) 25 core female head 16 photoelectric isolation output, the maximum reverse current 300mA
C) 25 core male 16 isolated inputs, the maximum input current 300mA
d) Front panel built-in USB interface, convenient user transmission cutting code
E) Extension of IO input and output; PWM input port of the analog input port;
1.5 Hardware configuration
1. Display: 7 inch high resolution 800*480 16000000 color high brightness LCD screen
2.Memory: 2 64MSDRAM
3 User space program: 256M
4 200MHZ system clock frequency
5.USB:USB1.1 interface front
6 Keyboard: electronic PCB film keyboard
7 Case: whole steel structure completely shielded, can really achieve anti electromagnetic radiation, anti-static, anti interference
