YIHUA 852D+ Hot Air Soldering Station With Soldering Iron Heat Gun Tool BGA Welding Station SMD Desoldering Station
Product Features
1.Two-in-one hot air gun and soldering iron, double LED digital display, stylishly compact, feature-rich, space-saving, and low shipping costs.
2.LED temperature display, more accurate temperature control, more stable temperature and more vivid operation.
3.Fine-control diaphragm pump is employed for powerful airflows; the smaller the nozzle of the gun, the stronger the airflow.
4.A cutting-edge ceramic-framed heating core for extremely stable and reliable performance!
5.Applicable to desoldering of several types of elements: SOIC, CHIP, QFP, PLCC, BGA; the smaller
the gun nozzle, the stronger of the force; suitable for desoldering of single soldering spots.
6.The machine features rapid heating,fast temperature compensation,High precision and stable
temperature control, this can effectively prevents cold solder joints.
7.The heating element employs an imported high-power heating element for fast temperature
compensation, particularly suitable for desoldering crude terminals, large joints, and difficult to reach spots, not to mention general solder joint desoldering.
8.This unit has an anti-static design effectively prevents damage to delicate components;
9.This product is CE approved.
Product Parameter
Machine parameter
Rated voltage :AC 220V±10% 50Hz
Machine power:660W(MAX)
working environment :0~40℃ relative humidity <80%
Storage temperature:-20~80℃ relative humidity <80%
Machine size :25.5*18.8*12.5cm
weight:4.5KG
Part of performance parameters
Hot air gun
Working voltage:AC 220V±10% 50Hz
Output power:550W
temperature range :100℃~500℃
Mode of airflow:Diaphragm pump
airflow:24-28L/min(max)
Temperature stability :±15℃ (static)
Display: LED
heater:Heating core ceramics heater
Solering iron
Working voltage:AC 26V±10% 50Hz
Output power:60W
temperature range :100℃~500℃
Temperature stability:±2℃ (static)
Display:LED
heater:Common heater
Tips to ground impedance:<2Ω
Tips voltage to ground:<2mV
