CNC 3018 500W/300W Kit 40W Laser Apply Nema17/23 Stepper 52mm

Spindle CNC Wood Router,Pcb Milling Machine,Craved On Metal

--XYZ three-axis actual stroke :300x180x60mm

--Aluminum Table Size: 300x180mm

--Material: Aluminium

--Stepper motor: Apply to Nema17/23 42/57BYG Stepper motor

--Screw: T8 anti-backlash nut, lead 4mm,

--Spindle hole diameter: 52mm

• Effect Laser Power: 40W

• Material: Aluminum Alloy+Plastic

• Light Color: Blue-violet

• Wave Length: 450nm

• Facula Form: Punctiform, Fixed Focus

• Input Voltage: 12V 5A

• Interface Parameter: Support TTL signal controls power

• Item Size: 116*40*40mm

• Item Weight: 300g

This kit is disassemble, needs the customer DIY assembling, needs certain electronic and the Mechanical Foundation.

500w kit：

--Machine frame*1pc

--500W spindle *1pc

--500W power supply *1pc

--3 axis controller *1pc

--ER11 chuck 8mm *1pc

--Collect 3.175mm *1pc

--Plate * 4Pcs

--Drill bit *10pcs

Gift：6* limit switch + 1* Emergency stop switch + 1* Tool setter

300w kit：

--Machine frame*1pc

--300W spindle *1pc

--300W power supply *1pc

--3 axis controller *1pc

--ER11 chuck 8mm *1pc

--Collect 3.175mm *1pc

--Plate * 4Pcs

--Drill bit *10pcs

Gift：6* limit switch + 1* Emergency stop switch + 1* Tool setter
