Affordable Wholesale [EU Stock] 6040 4-Axis 1500W ER11 Mach3 6040Z-S80 CNC Engraving Milling Machine Wood Lathe 220VAC DB25 Port

SKU: 1005004109887315
Safe Payment Guarantee:




  • 1 x 6040Z-S80 1500W 4-AxisCNC Router machine 220V

  • 1 x 4-Axis Control box

  • 1 x DB25 cable

  • 1 x Power cable(EU plug)

  • 1 x Tool box and tools

  • 3 x Aixs stepper motors

  • 1 x 1.5Kw water cooled spindle ER11

  • 1 x 1.5Kw Inverter 220V

  • 2 x connect wires

  • 1 x 75W water pump

  • User manual and set video will send by Email or give you link to download



6040Z-S80 model: 1.5K water cooled+1.5Kw VFD+Rotary axis


Machine Size:880x690x520mm

Movement length:XYZ=380x580x60mm

Max workpiece thickness:<=100mm

Work table size:750x480x20mm

Sliding unit:X-axis=20mm linear shaft,Y-axis=16mm support rail,Z-aixs=13mm linear shaft

Transmission unit:the X/Y/Z axis are all new ball screws,and good quanlity coupler

Stepper motor:57 series 2phase new stepper motors

spindle motor: 1500W water cooled spindle

spindle speed:24000 rpm

Max unload speed;5000mm/min

Engrave speed:300-2500mm/min according to the material

Support software:Mach3,EMC2,KCAM4,DB25 parallel cable

weight:round 55kgs contain packing

Accept engrave file:G code/tab/nc/ncc/txt

Main application: engrave for Wood,bamboo,normal PCB,PVC,PMMA,plastic,bamboo,duotone board(ABS)and etc nonmetal,also can engrave on gold,silver,copper,aluminium,Pb etc soft metal surface working,but not milling working


How to use

Please read the English user manual to see how to set up the software and how to use this machine.

1.Assembling and locating the CNC machine on steady desk well.

2.Make sure that your computer has a on-board parallel port output.

3.Installing a CNC control software and Drive such as the MACH 3 or EMC2 on your computer.

4.Connecting the control box with the CNC machine and you computer.

5.Fllowing our manual or guideline to set uo the software.

6.You can enjoy making you dream with using our CNC machine now.

Feature

·  Simple operation and installation.

·  More steady and strong equiped with aluminum alloy frame materials.

·  Can be controlled by computer

·  Mach 3 software is simple and intellgent

·  Can control the engraving more precise

·  Emergency stop button enhance security

·  Large engraving in soft wood,MDF board,native wood,PVC,Acrylic .

·  Stepping motor knob is useful for small positioning adjustment ,with steady and strong support structure.

·  Cover plates reducing pollution for the screws and shafts.

·  Thick 15mm aluminum 6063 plate,more stronger.

·  The reinforced and thickened machine body make transportation absolutely to be safer and longer life time.

·  The chrome shafts is not easy to deform,suitable for long time use.

·  Flexible coupling can be used for high torque transmission.

·  High Precision Stepping motor makes engraving more precise .

·  The NEW 1.5KW water-cooled VFD spindle is available operating for long time,which can reinforced the processing abilty of the machine and can be used to process aluminum alloy and hard wood.

·  This item already be equiped NEW 1605 ball screws. Anti-blackflash,high precision,long life circle.
