Product Description
Dividing Head for Milling Machine
Semi-Universal Dividing Head is a simple Index Center and can be used for direct and indirect dividing. Complete the gear, face, flute processing and no need accessories, the same construction as universal type. With rotary indexer, the 24 quick-dividing holes can complete 2,3,4,6,8,12,24 division indexding.
Adjustable Angle
Solid Construction
Clear & Accurate
MT2/MT3 Tailstock Adjustable
Rich Dividing Head Set
Tough Equipment & Tools, Pay Less
VEVOR is a leading brand that specializes in equipment and tools. Along with thousands of motivated
employees, VEVOR is dedicated to providing our customers with tough equipment & tools at incredibly
low prices. Today, VEVOR's products are sold in more than 200 countries and regions with 10 million
plus members worldwide. Why Choose VEVOR?
Premium Tough Quality
Incredibly Low Prices
Fast & Secure Delivery
30-Day Free Returns
24/7 Attentive Service
Adjustable 0°-90°
Vertical & horizontal milling machine with Head stock chuck for lathe.
Ruggedly Constructed
Ruggedly constructed hardened and ground worm gear. Reduction Ratio: 1:40.
Quick-dividing Design
Designed with rotary table and indexing chuck, 24 quick-dividing holes can complete 2, 3, 4, 6, 8, 12, 24 division indexing.
MT3/MT2 Tailstock Adjustable
Ball bearing precision, smooth turning. One more dead center for free.
Universal 3 Plates
3 dividing plates for different sizes with easy indexing of divisions from 2 to 50 and most numbers up to 380.
Wide Application
Ideal choice for various uses in milling, grinding and drilling work.
Dividing Head With 6In 3-Jaw Chuck
Chuck Diameter: 6"/160mm
Spindle Speed: 2500Rpm
Swing: 6-1/2"/168mm
Center Height: 5"/128mm
Reduction Ratio: 1:40
Tailstock: MT3
Package Content
1 x 6" Dividing Head
2 x Dividing Plate
3 x 6" Chuck Jaw
1 x Dead Center
1 x Tailstock
Some Related Accessories
Dividing Head With 5In 3-Jaw Chuck
Swing: 6-1/2"
Center Height: 3-15/16"
Headstock Taper: MT2
Weight: 23 kg (50.7 lbs)
Package Dimensions: 410*235*205 mm (16*9*8 in)
Package Content
1 X Dividing Head
3 X Dividing Plates
1 X Tailstock
1 X 125 mm 3-Jaw Chuck
Dividing Head With 4In 3-Jaw Chuck
Chuck Diameter: 4"/100mm
Center Height: 4"/100mm
Material: HT200
Reduction Ratio: 1:40
Tailstock: MT2
Package Content
1 x Dividing Head
1 x Tailstock
Some Related Accessories
【Adjustable Angle】- The semi universal dividing head features 6" / 5" / 4" 3-jaw chuck; Headstock adjustable from the horizontal position to 90 degree upward. With 6In 3-Jaw Chuck: Swing: 6-1/2"/168mm, Center Height: 5"/128mm. Free 3 more jaws for 6" chuck. With 5In 3-Jaw Chuck: Swing: 6-1/2"/168 mm. Center Height: 3-15/16". With 4In 3-Jaw Chuck: Center Height: 4"/100mm. Free 3 more jaws for 4" chuck.
【Solid Construction】- Made from HT200 to be long life. Rigid frame provides high accuracy with little backlash for a smooth rotation. Reduction Ratio: 1:40.
【Clear & Accurate】- Dividing head milling machine with laser engraving scales. The 24 quick-dividing holes can complete 2, 3, 4, 6, 8, 12, 24 division indexing. One circle for 360 degrees, one scale stands for 1 degree.
【MT3/MT2 Tailstock Adjustable】- Huge live center for heavy duty workpieces. Ball bearing precision; turns smoothly. Tailstock: MT3/MT2. One free dead center.
【Rich Dividing Head Set】- 3 dividing head index plates are attached along with the dividing head for indirect dividing in any division indexing 2-50, 51-380 except prime numbers and certain other numbers.
