Affordable Wholesale 3.2KW water cooled spindle motor 4 bearing 220V 380V diameter 100MM ER20 for cnc engraving cutting machine GDZ-100-3.2

SKU: 4000378252713
Safe Payment Guarantee:

ATT : AC220v is ok,but need use inverter for output,can`t use household electricity directly

Material : spindle cover is 304 stainless steel,water jet is high pressure casting aluminum pipe,copper coil

Power connection

GX16 waterproof aviation plug,(1/2/3)connect inverter(U/V/W)in turn,4 connect inverter earth wire

Packing list : spindle*1set   aviation plug*1 set    ER collet*1pcs


Model

GDZ-100-3.2

Rev(rpm)

24000

Power(kw)

3.2

Voltage(V)

380(220V is optional)

Current(A)

12A

Frequency(HZ)

400

Cool type

 water cooling

Diameter(mm)

105

Lubricate

Grease

Bearing

7005C P4*2  7003C P4*2

Collet(mm)

ER20(standard size 6MM diameter)

Repair time

Bearing(half year), spindle(one year)

Size

100mmx260mm
