DIY CNC 3020 2200W USB 4axis Metal Wood Carving Machine Kit 800W 1500W Ball Screw Woodworking Router Akuminum Engraving Milling Machines
Free Gift:
Spindle dust cover x 1piece
Model and Technical Parameters:
MODEL | CNC 3020 |
Axis | 3axis /4axis |
Interface | LPT and USB2 IN 1 |
Toolauto-checking | Yes |
Type of screw | 1605 Ball screw |
Machine Dimensions： | 560X450X450mm |
Rack material： | 6061 and 6063 Hard aluminum alloy (The unique and dedicated mold extrusion profiles, Let counterfeiters dwarfs.) |
Engraving area： | 300X200mm |
Z-Axis Stroke： | 60mm, Engraving depth depends on the length of the tool edge |
Acceptable material thickness： | ≤60 & ≤120mm |
Rail type： | Chromeplate shaft+Linear Bearings,Surface hardening 61HRC |
Spindle motor： | 800W(65mm diameter) 1500W(80mm diameter) 2200W (80mm diameter) VFD water cooling spindle |
Collet type： | ER11/ER16/ER20,1/8"(3.175mm) Collet |
Stepper motor and drive： | two-phase hybrid stepping motor3A/PHASE,150N.cm, 8 segments drive. |
Maximum operating speed： | 4000mm/min (Engraving speed :300-3000mm/min) |
Repeat positioning Accuracy： | ≤0.03mm |
Software Compatability： | Mach3/Emc2/Kcam, (Type3,Wentai, ArtCAM,coppercam) |
Command code： | G code/.nc/.ncc/.tab/.txt |
Rotation Axis (4th Axis) Description: | Chuck Size: 50mm self-centering chuck Center height: H = 51mm Clamping diameter: 50mm or less Deceleration mode: synchronous wheel / belt Deceleration ratio: 4:1 Stepper motor:NEW 57 type / 3A Stepper Drive: T65-axis drive Positioning accuracy: 0.075 ° Weight: 4kg |
