Improved products and new products

1. The movable pins improve the accuracy and better adapt to Holes on the actuator arms of hard drives;

2. The fixed pins improve the accuracy and better adapt to Holes on the actuator arms of hard drives;

3. The handle is modified into a drop shape for better operation;

What is the HDDOR tool?

HDDOR WD 2.5” – 3.5” Ramp Set is a set of head replacement tools
which can be used to safely and easily replace heads on almost all 2.5” and 3.5” Western Digital hard drives which “park heads” on a ramp. Set contains 6 of head replacement tools: WDC 3.5” Ramp p1, WDC 3.5” Ramp p2-3, WDC 3.5” Ramp p4, WDC 2.5” Ramp p1-2, WDC 2.5” Ramp p3 and WDC 2.5” Ramp p4.

WDC 3.5” Ramp p1

This head replacement tool can be used on 3.5” Western Digital hard drive models AAKS, AAJS, AAJB and all other models with 1 platter from families:

Pinclite, Pinnacle, Tahoe, Tahoe LT, DragFly1, Sequoia, Sequoia PMR and STG Twin Lakes.

WDC 3.5” Ramp p2-3

WDC 3.5”Ramp p2-3 head replacement tool can be used on 3.5” Western Digital hard drive models AAKS, AAJS, AAJB, AAKB, EADS, EARS and all other models with 2 or 3 platters from families: Tornado, Tornado PATA, Tornado2R, Tornado 2PMR, Tornado 2D, Atlantis, Atlantis PATA, Spider, Gekko,DragFly2, DragFly3, Kermit, Sadle G6, Sadle 2D and Sadle BK.

WDC 3.5” Ramp p4

WDC 3.5” Ramp p4 head replacement tool can be used on 3.5” Western Digital hard drive models AAKS, AACS, EADS, EARS, EACS, EZRX and all other models with 4 platters from families: Jupiter, Hulk and DragFly4. As there is no conceptual difference between these three tools for 3.5” hard drives, we will explain only the functioning of WDC 3.5” Ramp p2-3 tool. In the case of WDC 3.5” Ramp p4 and WDC 3.5” Ramp p1 apply the same procedure.

WDC 2.5” Ramp p1-2

This head replacement tool can be used on 2.5” Western Digital hard drive models BEVT, BEKT, BEVS, BMVV and all other models with 1 or 2 platters from families: Mariner, Mercury, Zephyr, Marn5 4K, Esprit, Europa and other.

WDC 2.5” Ramp p3

This head replacement tool can be used on 2.5” Western Digital hard drive models TMVV, TPVT, TMVW and all other models with 3 platters from families: Helios, Shasta 3D and other.

WDC 2.5” Ramp p4

This head replacement tool can be used on 2.5” Western Digital hard drive models  NMVW and all other models with 4 platters from Shrek and Shrek LT familie.

They cannot solve incompatibility issues. They can only support hard disk drives, with easy and safe head replacement.

Head replacement tools (head combs) offer a safe and easy way to replace the magnetic heads of hard disk drives. These tools can ensure a non-contact head replacement.

That means there is no contact between the heads, or between heads and platters when you disassemble donor heads and install heads on malfunctioning hard disk drives.

Heads can be transferred from donor to malfunctioning hard disk drives in a few easy steps. During the process of head replacement, heads do not touch each other or make any contact with the platters. Each head change tool is designed for specific brands and models of hard drives, and these tools are not generic since mechanics of different hard drives doesn't match.

These tools offer as one-piece, not as a pair.

Supported models:

The list of tools may be updated as we get information from the market. HDDOR isn’t responsible if the producer change the architecture of a drive from the list above.
