Electric Hand Rug Tufting Machines Rug Making Tools Electric Carpet Weaving Tufting Gun ( Can do both Cut Pile and Loop Pile )
TD-01 CUT PILE
Electric carpet tufting gun, carpet weaving machine, flocking machine, industrial embroidery machine, cut pile knitting machine (cut pile)
[Good performance]: This knitting gun has a very wide range of applications. It can be used for weaving different types of carpets. The motor speed can reach 2400RPM or higher for high-speed tufting, which improves work efficiency. At the same time, it is quieter and will not make a loud noise and almost all yarns are available, it is advanced special equipment that can greatly improve work efficiency in modern production.
[Meet various needs] The speed of this tufting gun studio can reach 5-40 stitches per second, and the adjustable carpet height is 7-21mm, which increases the production efficiency by 80-100 times and saves more than manual knitting Manpower and time.
[Safety protection]: The tufting gun has over-voltage, over-current, and short-circuits protection functions, which can avoid accidents during use
[Lightweight and portable] The tufted carpet gun is a portable electric knitting tool. The product is only 1.4kg. You can easily lift it for operation. After use, it can also be stored in a cabinet or trunk without taking up too much space.
[Simple operation] Easy to operate and master, it is not only suitable for high-speed knitting and flexible movement, but also suitable for mobile table work, which can knit a variety of fancy patterns.
Specification:
Product name: Electric tufting gun (cut pile)
Model:TD-01
Voltage range: 100V/220V
Power: 70W
Frequency 50-60 HZ
Weight:1.4 kgs
Speed Range: 5-40 stitches/sec adjustable
Pile high: 7-21 mm adjustable
Output DC: 24V small adapter
Safe protection: Has over-voltage, over-current, and short circuit protection
Package: Carton box size: 37*27*8cm; G.Weight: 2.3kg
Advantages: working very quietly; lightweight; wide range of voltage.
Simple operation, easy to master.
Exquisite structure, Easy to be repaired.
Suitable for moveable active working method.
The production efficiency is 80-100times than that of manual.
TD-02 LOOP PILE
Electric carpet tufting gun, carpet weaving machine, flocking machine, industrial embroidery machine, cut pile knitting machine (loop pile)
[Good performance]: This knitting gun has a very wide range of applications. It can be used for weaving different types of carpets. The motor speed can reach 2400RPM or higher for high-speed tufting, which improves work efficiency. At the same time, it is quieter and will not make a loud noise and almost all yarns are available, it is advanced special equipment that can greatly improve work efficiency in modern production.
Specification:
Product name: Electric tufting gun (loop pile)
Model:TD-02
color: blue
Voltage range: 110V/220V
Power: 66W
Frequency 50-60 HZ
Weight:1.38kgs
Speed Range: 5-40 stitches/sec adjustable
Pile high: 4-14 mm adjustable
Output DC: 24V small adapter
Safe protection: Has over-voltage, over-current, and short circuit protection
Package: Carton box size: 37*27*8cm; G.Weight: 2.3kg
Advantages: working very quietly; lightweight; wide range of voltage.
Simple operation, easy to master.
Exquisite structure, Easy to be repaired.
Suitable for moveable active working method.
The production efficiency is 80-100times than that of manual.
ZQ-II Cut & Loop Pile
The utility model has the advantages of simple operation, easy grasping, long service life, less
failure and convenient adjustment, and is an advanced special equipment which is indispensable for the
carpet industry to move toward modern production. At the same time, it also produced a huge change in
the traditional hand-made carpet.
ZQ-II electric carpet weaving gun is a portable and portable electric needle-punching machine.
It has the characteristics of high-speed woven and flexible movement.
It is suitable for mobile station operation and can weave many types of fancy.
Its production efficiency is manual. 80-100 times of production, it is a multi-purpose special machine.
Specification:
Model: ZQ-II
Machine weight: 2800g
Motor speed: 2400rpm
Carpet thickness: 9-18mm
Power source: 220V/50-60Hz(110V is Equipped with transformer.if you mind,please don't place order )
Input power: 240w
