18pcs HSS Keyway Broach Set 4mm 5mm 6mm 8mm Broaches 12-28 Bushings Shims Set Keyway Tool for CNC Machine Wooden Box Package
Product includes:
Broaches*4pcs
Collared bushings*9pcs
Shims*5pcs
Product description:
4 broaches: 4mmB1 ,5mmB1, 6mmC1, 8mmC1
9 Collared bushings: 12,14,16,18,20,22,24,26,28
5 shims
Product features:
4 broaches and 9 bushings = 18 keyway combinations
All necessary shims
Broach Size | Style | Correction height(mm) | Leading height(mm) | Broach Dimensions*(mm) | Keyway Width(mm) | Length of Cut * min.-max. |
4mm | B1 | 10.8 | 9.66 | 6.45X171.5 | b=4.01 | 19/64 - 1 11/16 |
5mm | B1 | 10.8 | 9.66 | 6.45X171.5 | b=5.01 | 19/64 - 1 11/16 |
6mm | C1 | 16.64 | 15.02 | 9.64X298.5 | b=6.01 | 25/64 - 2 1/2 |
8mm | C1 | 15.95 | 14.62 | 9.64X298.5 | b=8.01 | 25/64 - 2 1/2 |
one year warranty
