Total power <300W
Brand model of laser tube： RECI W2
Laser power maximum value :100W
Laser type :CO2 laser engraving machine
Laser tube working time :7000-10000 hour
Power supply AC :220V
Working area :600*1000 mm
Cutting depth :0-15 mm (different material differ)
Engraving speed :0-500mm/s(Linear Guides weight is heavier than the circular rail,
the accuracy is better, the speed will be slower,the service life will be longer)
Laser focal length: 6.35cm
Operation systems:Windows 8, 7 (64 or 32 bit), XP
Cutting speed :0-50mm/s
Lifting platform :0-200 mm Honeycomb Worktable
Locating precision :<0.02 mm
Min shaping character Character: 2*2mm, Letter: 1*1mm
Working temperature :5℃-45℃
Working humidity :5%-95%
Resolution ratio : ≤1000dpi
Data transfer interface :USB 2.0 (offline)
Cooling :Water Cooling and protection system with chiller
Graphic Format :Supported (BMP,JPEG,PLT,CDR,AI,)TIFF,PCX,DIB,TIF
Work software :RDworks
Color separation :Yes
Auto-focus :Yes
Emergency Stop Button:Yes
Limit switch:Yes
Warranty : 1 Year
Protection :Emergency stop button and Stop working when water broken
Machine Dimensions :140*95*65 cm
Machine Package :Wooden box with foam inside
