Introduction
The CNC 6090 Easily produce name badges, equipment tags, small signs, plaques and awards, gift items, pet tags,ID tags, electrical tags, military name tags, desk plates, or mark industrial parts.
Whether you are a startup business, or a model enthusiasts, or looking to add a machine to supplement the capacity of an existing operation, the CNC 6090 is a great fit.
We look forward, CNC 6090 will become your good helper
In addition, it can be upgraded to be installed a rotational axis.
Linear Guide Rail,More Precise Stepping Motor
The engraving process is visible as controlled by computer
Simple operation and installation
1 year machine part and 6 months electrical parts,stepping motor,spindle Free Warranty
Technical Parameters
MODEL |
6090L |
Machine Dimensions: |
900 * 1200 * 600mm |
Rack material: |
6061 and 6063 Hard aluminum alloy |
Table size |
640 * 1080mm (20mm aluminum alloy T table) |
Engraving area: |
560 *850mm |
Z-Axis Stroke: |
120mm, Engraving depth depends on the length of the tool edge |
Acceptable material thickness: |
140mm |
Rail type: |
Linear guide rail TRH20 (more precise moving) |
Type of screw: |
Taiwan TBI Ball screw 1605 |
Spindle motor: |
1.5KW/2.2KW VFD water cooling spindle , 0-24000r/min |
Collet type: |
1.5KW ER11/2.2KW ER20,1/8"(3.175mm) and 6mm Collet |
Stepper motor and drive: |
two-phase 57/3A |
Maximum operating speed: |
4000mm/min (Engraving speed : 300-3000mm/min) |
Repeat positioning Accuracy: |
0.03mm |
Communication interface: |
Parallel port or USB port |
Tool auto-checking |
yes |
Software Compatability: |
Mach3 (Type3,Wentai, ArtCAM, coppercam) |
Command code: |
G code/.nc/.ncc/.tab/.txt |
Machine weight: |
150kg |
Rotation Axis (4thAxis) Description: |
Chuck Size: 80mm self-centering chuck Center height: H = 71mm Clamping diameter: 80mm or less Deceleration mode: Gear box Deceleration ratio: 20:1 Stepper motor: 57 step motor current 3A Positioning accuracy: 0.075 ° |
Note:
This machine have other spindle, For example 800W and 1.5KW;
But the price may be different;
If you need other spindle ,please message us or contact us, thank you very much;
Attribute |
3axis |
4axis |
||
Parallel port |
USB port |
Parallel port |
USB port |
|
Axis |
3axis |
3axis |
4axis |
4axis |
Interface |
Parallel port |
USB port |
Parallel port |
USB port |
Weigh |
150 |
150 |
158 |
158 |
Packing list |
||||
1× Engraving machine |
√ |
√ |
√ |
√ |
1× Control box |
√ |
√ |
√ |
√ |
1× Power cable |
√ |
√ |
√ |
√ |
1× Parallel port cable |
√ |
ⅹ |
√ |
ⅹ |
1× USB port cable |
ⅹ |
√ |
ⅹ |
√ |
1× Tool package |
√ |
√ |
√ |
√ |
1× Rotation axis |
ⅹ |
ⅹ |
√ |
√ |
1×tool auto-checking instrument |
√ |
√ |
√ |
√ |
1x water pump |
√ |
√ |
√ |
√ |
1× CD (if not get, may be lost in customs, please contact us) |
√ |
√ |
√ |
√ |
( one wooden case package ,package size : 116*92*69cm ,165KG)
Our Machine has this switch for XYZ axis , more professional and perfect :
Our CE Certificate :
