Affordable Wholesale Mini Router 3020 USB Port 300x200mm GRBL Mach3 Software System 300W 500W 800W Optional CNC Engraving Milling Machine

SKU: 1005003652577960
Safe Payment Guarantee:

Mini CNC Router 3020 300x200 Engraving Drilling and Milling Machine



Introduction

The CNC router is suitble for Industry, Technology Research, Advertising Design, Arts Creation, Teaching, Student Project and Hobby Purposes.

The cnc router is designed for large area engraving work such as Industrial or Hobby Prototype Building, Building Model Making, PCB, Advertising Signs, Artwork, Crafts, Aircraft Models, RC Model parts, etc. So, you can do engraving work at office or home.


We will provide
software and use manual in English as below:




Model and Technical Parameters

MODEL

3020

Software System

GRBL

MACH3

Spindle Motor:

300W DC

500W DC

800W VFD

300W DC

500W DC

800W VFD

Spindle speed:

0-12000r/min

0-12000r/min

0-24000r/min

0-12000r/min

0-12000r/min

0-24000r/min

Interface

USB port

USB port

USB port

USB port

USB port

USB port

Weigh

25

25

26

25

25

26

Machine Dimensions:

510X450X460mm

Rack material:

6061-T6 Hard aluminum alloy (15MM)
(The unique and dedicated mold extrusion profiles, Let counterfeiters dwarfs.)

Engraving area:

300X200mm

Z-Axis Stroke:

60mm, Engraving depth depends on the length of the tool edge

Acceptable material thickness:

80mm

Size of table

300x440mm

Rail type:

Chromeplate shaft + Surface hardening 61HRC  (X16mm  Y16mm  Z12mm)

Type of screw:

Ball screw 1605

Collet type:

ER11,1/8"(3.175mm) Collet

Stepper motor and drive:

two-phase hybrid stepping motor 57BYGH56

Maximum operating speed:

4000mm/min (Engraving speed :300-3000mm/min)

Repeat positioning Accuracy:

0.03mm

Command code:

G code/.nc/.ncc/.tab/.txt
