Introduction
The CNC router frame need self-assembled for DIY amateur;
The cnc router is designed for large area engraving work such as Industrial or Hobby Prototype Building, Building Model Making, PCB, Advertising Signs, Artwork, Crafts, Aircraft Models, RC Model parts, etc. So, you can do engraving work at office or home.
Model and Technical Parameters
MODEL | CNC 6040 Frame | |
Machine Dimensions | 860X690X550mm | |
Rack material | 6061 and 6063 Hard aluminum alloy | |
Engraving area | 600X400mm | |
Z-Axis Stroke | 80mm, Engraving depth depends on the length of the tool edge | |
Acceptable material thickness | ≤80mm | |
Rail type | Chromeplate shaft + Linear Bearings, Surface hardening 61HRC | |
Diameter of Spindle motor | 65mm ( 52mm & 80mm optional) | |
Stepper motor size | 57mm | |
Repeat positioning Accuracy | ≤0.03mm |
