Affordable Wholesale DIY Mini Cnc Router 3020 PCB Milling 400W Spindle 5 Axis Metal Engraving Machine Wood Carving USB Port with ER11 Collet Cutter

SKU: 32841937773
Safe Payment Guarantee:


DIY 3020 CNC Router Engraving Drilling and Milling Machine   if you need bigger working size cnc machines , please press the button about 300*400mm/300*600mm .

Package has CD , CD include detail english manual and software and operate video , it is very easy for operate the machine


Introduction

This is a very good era,in the past we only can see the CNC machine equipment in factory, but now,

the CNC equipment has been into our lives;

Whether you are a small or medium enterprises managers, project engineers, CNC enthusiast or artists,

related students, there are something on this machine will attract you;

It can help you processing a lot of parts, whether you are modeling or home decoration or creative DIY.

It can help you intuitively to learn CNC knowledge. And testing learning outcomes in real time.

Warranty

More Precise Stepping Motor

Simple operation and installation

1 year machine part and 6 months electrical parts,stepping motor,spindle Free Warranty



Model and Technical Parameters

MODEL

3020 metal

Attribute

3axis

4axis

5axis

Only frame

Axis

3axis

4axis

5axis

3axis

Interface

USB Port

usb port

USB Port

No

Spindle Motor:

400W

400w

400W

No

Weigh

22

29

26

16

Max. working stroke

XYZ=180*270*95mm

Acceptable material thickness

≤95mm

Rail type

X Y 1605 ball screw, Z 1204 ball screw,

12 mm optical axis

Spindle motor

400WDC spindle , 0-9000r/min

Collet type

ER11,1/8"(3.175mm) Collet

Stepper motor and drive

57HS56

Repeat positioning Accuracy

0.02mm

Communication interface

USB Port

System requirements

Win-XP / Win 7 Win 8 Win10

Software Co

patability

Mach3/Emc2/Kcam, (Type3,Wentai, ArtCAM, coppercam)

Command code

G code/.nc/.ncc/.tab/.txt

Machine weight

22kg

Rotation Axis

Description:

The fourth axis gear ratio: 4: 1 (57 two phase 3A stepper motor 1.2N)

The fifth axis reduction ratio: 5: 1 (57 two phase 3A stepper motor 1.2N)

Four jaw chuck 60MM

The clamping: Positive direction:40mm; In the opposite direction:70mm

Fourth axis Center height: 55MM

The fifth axis higher than the 4th axis 44 mm

Bottom fixed hole distance: 150mm x 85mm


If you choose '5axis machine' ,package will include one 5th axis ,without 4th axis !
