Affordable Wholesale Offline automatic three-axis glue dispenser controller system V7V8 version handle type operating system glue dispenser

SKU: 1005004291193013
Safe Payment Guarantee:

product description

This product is a low-cost, high-concentration, high-integration intelligent dispensing machine control system tailored by the company's professional CNC team for the dispensing machine industry.


Function introduction

1. The handheld box adopts 320*240 high-resolution color screen and full Chinese operation interface, which is easy to learn and use.

2. It has graphic elements such as drawing points, straight lines, polylines, three-dimensional arcs (space arcs), circles, runways, rectangles, coatings, automatic fillets, irregular three-dimensional splines, etc.; rich manual teaching functions and graphics Preview function.

3. It has the function of conditional jump, and the function of rotating the needle with double MARK points.

4. It has the function of jump selection, which can select multiple discontinuous instructions at the same time.

5. It has the function of command movement, which can move the edited command to the target position.

6. With breakpoint execution function, it can start execution from a specified point.

7. It has the functions of area array copy, offset operation, batch editing, single-step operation, I/O input and output, etc.

8. With automatic execution, automatic reset, output setting, processing time timer and other functions.

9. There are four different wire drawing process options, which can solve technical problems such as wire drawing.

10. Support DXF and PLT file import, automatic path optimization function.

11. After editing the action parameters, download the action parameters to the controller through the serial port, and then it can run independently offline. Action parameters can also be saved in the handheld box for easy recall; and graphics can be copied and saved between devices.

12. The handheld box can store hundreds of processing files, and each file can support 8000 instructions, which can be called out when used.

13. The hardware has 4 gun channel controls, 4 general outputs, 8 inputs, and 12 high-speed pulse outputs; the control dispensing time precision is 1ms.

14. Each action command has an independent glue opening delay, glue closing delay, ejection height, and independent advance glue closing function. The flexible batch modification function can improve editing efficiency and solve the problem of glue stacking.

15. Support batch modification of parameters by type.


Features

Controller Hardware Features

Number of motor axes: 3 axes (XYZ)

Pulse frequency: 200K

Number of IO ports: 8 dedicated inputs (XYZ origin, start/pause, pause, reset/emergency stop button), 4 dedicated glue gun outputs (4 glue gun switch control, direct drive solenoid valve, drive current 2A). 4 general-purpose I/O outputs, 8 general-purpose I/O inputs, 12 high-speed "NPN open collector" 5-24VDC outputs, rated current 0.5A.

IO input type: optocoupler isolation input.

Storage capacity: 16M

Interface: DB44 interface

Working voltage: 24V DC,

Working temperature: -10-60℃

Storage temperature: -40℃-70℃

Working humidity: 40%-80%

Storage humidity: 0%-95%


Handheld Box Hardware Features

Interface mode: equipped with USB interface and serial port, the USB port is used to connect to the computer, this function is temporarily reserved. The serial port is used to connect the handheld box.

Storage method: FLASH chip.

Display configuration: resolution 320*240, 3.2-inch color LCD screen.
