Aluminum CNC 3018 Plus Frame 300W 500W CNC 3018 Wood Router NEMA17 Stepper Motor PCB Milling Engraving Machine 5.5W 15W Laser
5.5W/15W laser for Optional.
Parameter
Machine size: Length 422mm* Width 414mm* Height 350mm
XYZ axis actual stroke: 300*180*60mm
Aluminum Table Size: 300*180mm
Material: Aluminum
Stepper motor: Nema17 48mm Stepper motor
Screw: T8 stainless steel screw, lead 4MM, POM anti-backlash nut
Spindle hole diameter: 52mm
Laser module diameter: 40mm
Control software: Laser GRBL control, CNC CANDLE control
Spindle: 300W/500W Optional (ER11)
Laser: 5.5W/15W/30W Optional
Power Supply: 24V 5A
Supported System: Windows XP/ Win 7/ Win 8/ Win10
Suitable for material: CNC: Wood, Acrylic, PVC, Nylon, Epoxy Resin, Glass Fiber PCB, POM, Carbon Fiber Board….
Laser: Wood, Plastic, Anodized, Stainless steel(only can marking)
