Affordable Wholesale 【Free Ship】3018 Pro Max Metal Frame CNC Laser Router Machine Engraver GRBL Controller Pcb Pvc Milling, 2.5W 5.5W Laser Module

SKU: 1005002964540929
Safe Payment Guarantee:

Good News: We have warehouse in some countries, check as bellows



Package include:


1set GRBL 3018 Pro MaxCNC Laser machine kit(without laser), if you need laser, pls contact us before you order.
1 x 775 Spindle Motor with ER11 Collet
1 x GRBL control board
1 x Hand Controller
10 x 20°0.1mm drill bits
1 x Set of allen wrench
1 x Power Supply
1 x U disk
English manual link will send to your email.
Notice: The machine for a full set of spare parts, shall be installed by the buyers,the package include the U Disk , with detailed user manual and free software,buyers don‘t need to worry about machineAssembly.We suggestcnc-based buyers to buy,This machine is not industrial grade level.



 Basic Paraments


Item Name:CNC 3018 Pro Max 3-Axis Laser Engraving Machine

Work area:300x180x45mm(approx.11.81x7.08x1.77inches)

Mesa: 300x180mm(approximately 11.81x7.08inches)

Frame: 420x350x270mm(approximately 16.53x13.78x10.63inches)

Material: PA6 Nylon+Aluminum porfile

Workable thickness: 45mm(height 64mm)

Stepper Motor:3x42 stepper motors

Spindle:775 Spindle motor(12-36V);24V:1000rpm

Chuck: ER11 (3.175mm default)

Connection: PC-USB connection(Windows XP/ Win7/Win8/Win10/offline line)

Power supply: 24VDC power adapter(110-240V input voltage)

Screw:T8 T-screw, 4mm lead

Control Board:Upgrade version with  shell and fan, best for dust proof, cooling and extending to affect time and service life, firmware GRBL1.1F, offline wiorking support.

Using with 775 spindle motor (cutters):

Design software: CAM

Control software:GRBL (GRBLcontrol / Candela)

File format: G code (gcode / txt / nc / ncc / tap / ...)

Spindle power: 120W (24V)

Spindle speed: 10000rpm

Processing method: relief / drilling / cutting

Workable material:wood / plastic / PCB / acrylic / plywood / ...



  Advantage


1. Add laser protection cards on both sides to make laser testing more convenient.

2. DRV8852 Driver GRBL1.1F control board firmware V3.4, stable performance, overcurrent protection stepper motor to avoid damage.

3. The updated control board is with shell and fan, better for dust proof and cooling, and the etching time and service life will be extended.

4. Laser engraving-import the photo directly for engraving, needn't program and design which is very simple and convenient.




 2.5W Laser Module





 5.5W Laser Module
