Affordable Wholesale Smoke Filtering System Parts For NeoDen IN6,IN12,IN12C Reflow Oven

SKU: 1005004653907416
Safe Payment Guarantee:

Note:The list product price 199USD not include the delivery fee and import tax/tariff fee.

No Pedestal/working table include.If want,click below link:


IN6 without Pedestal:www.aliexpress.com/item/1005004545628410.html

IN6 with Pedestal: www.aliexpress.com/item/1005004545628410.html


Smoke Filtering System Parts For NeoDen IN6,IN12,IN12C Reflow Oven

Features:

1.Full convection, excellent soldering performance.

2.6 zones design, light and compact.

3.Smart control with high sensitivity temperature sensor, the temperature can be stabilized within + 0.2℃.

4.Original high-performance aluminum alloy heating plate instead of heating pipe, both energy-saving and high-efficient, and transverse temperature difference is less than 2℃.

5.Original built-in soldering smoke filtering system, elegant appearance and eco-friendly.

6.Heat insulation protection design, the casing temperature can be controlled within 40℃.

7.Household power supply, convenient and practical.

8.ESD tray, easy to collect PCB after reflowing, convenient for R&D and prototype.

9.Several working files can be stored, freely switch between Celsius and Fahrenheit, flexible and easy to understand.

10.Japan NSK hot-air motor bearings and Swiss heating wire, durable and stable.

11.Reinforced heavy-duty carton package, light-weight and environment-friendly.

12.PCB soldering temperature curve can be displayed based on real-time measurement

13.Approved by TUV CE, authoritative and reliable.


Details:




Parameters:Power requirements: 110/220VAC 1-phaseRated power max.: 2000 WattsHeating zone quantity: upper3/down3Heating type: nichrome wire and aluminum alloy heatingCooling zone quantity: 1Conveyor speed: 15 - 60 cm/min (6 ndash 23 inch/min)Standard Max Height (mm):30mmOperation direction: leftrarrrightTemperature control range: Room temperature~300℃Temperature control accuracy: plusmn0.2℃PCB temperature distribution deviation: plusmn1℃Soldering width: 260 mm (10 inch)Length process chamber: 680 mm (26.8 inch)Bottom cooling fans at offload sectionHeat-up time: approx. 15 min.Dimensions: 1020 x 507 x 350 mm (L x W x H)Packing Size:112*62*56cmNet weight: 49 kgGross Weight:64KG


Warranty:

The complete machine has a warranty period of Two year from the time   of purchase and lifelong service support as well as a long-term  factory price supply. We provide online Q/A and trouble shooting  support and technical advice service.
