high quality 3KW water cooled spindle motor 380V GDZ-100-3.0
Material :spindle cover is 304 stainless steel,water jet is high pressure casting aluminum pipe,copper coil
Power connection
GX16 waterproof aviation plug,(1/2/3)connect inverter(U/V/W)in turn,4 connect inverter earth wire
Packing list : spindle*1set aviation plug*1 set ER collet*1pcs
Model | GDZ-100-3 |
Rev(rpm) | 24000 |
Power(kw) | 3 |
Voltage(V) | 380(220V is optional) |
Current(A) | 12A |
Frequency(HZ) | 400 |
Cool type | water cooling |
Diameter(mm) | 100 |
Lubricate | Grease |
Bearing | 7005C P4*2 7003C P4*2 |
Collet(mm) | ER20(standard size 6MM diameter) |
Repair time | Bearing(half year), spindle(one year) |
Size | 100mmx220mm |
