15W Laser AS-5,10000mw/15000mw CNC DIY Laser Engraving Machine/Metal Engrave Marking Machine Engraving Area 14 x 20cm
Package Included:
- 20*14cm 10w/15w Laser Machine*1
- Power cord *1
- 10*10cm Metal lift platform 10*10cm *1
- Glasses * 1 pair
- USB line *1
(Software can download via our link) Laser Parameter:Interface: USBPower: 12v/4Athe laser power: 10W/15Wcan be carved material: stainless steel, iron, anodised aluminium, ceramics, stone, wood, bamboo, leather, plastic, etc.Note: nanosecond timing of serial data transmission substantially without delay, power adjustable, high power pulsed laser, lifts fast focusing, targeting low light gray print! Specification:Construction: mobile gantry, body Aluminum + AcrylicDrive system: stepper motor, stepper precision: 0.00625mmEngraving area:20*14cmEngraving speed: 0.02 to 0.2 sec / pixelLaser power: pulse 10w/15w (100ns Duty 50%)Carving materials: stainless steel, iron, anodised aluminum, ceramics, stone, wood, bamboo, leather, plastics, etc.Height restrictions: noInterface: USBFeatures: Software 255 adjustable laser power, low-light positioning, positioning freedom, gray, shortest path algorithmPower supply: external adapter, DC 12V 4A, input AC 100V-240V, 47Hz-66HzSoftware: machine developed specifically for use ac master software, support Chinese, English, Russian, 4 languagesSupport win7, win8, win10Super-reduced instruction, 1 byte of instruction accounted for more than 40%.Explain arduino + grbl faster than the speed more than 30 times, and instantly be able to complete the task of interpretation active instruction; shortest path algorithm can shorten the time.FAQ:
1. Q: Can it engrave/mark on gold or silver? Can it engrave/mark on all metal materials?
A: No, this machine can only mark on some stainless steel, iron and colorized anodised aluminum. It can not engrave/mark on gold or silver.
2. Q: Can it engrave any depth on metal?
A: No visible depth, it can only leave a marking.
3. Q: Can it cut wood?
A: It can cut normal wood of 3-4mm, but not plywood. Other wood material has not been tested yet.
4. Q: Can it engrave on carved surfaces(cylinder or alike)?
A: No, it works only on flat surface.
