YOOCN 8060Z Engraving Drilling and Milling Machine 6040 2200W USB CNC Router Engrave 2.2KW Spindle
Model and Technica Parameters
MODEL | 600X400MM/800X600MM | |||
Attribute | 3axis | 4axis | ||
Axis | 3axis | 4axis | ||
Interface | USB port | USB port | ||
Limit switch | Yes | Yes | ||
Tool auto-checking | Yes | Yes | ||
Spindle Motor: | 1500W/2200W | 1500W/2200W | ||
Machine Dimensions： | 6040Z:870X670X560mm 8060Z:1130X890X610mm | |||
Rack material： | 6061-T5 extruded aluminum alloy | |||
Engraving area： | 6040Z:575X380mm 8060Z:790X580mm | |||
Z-Axis Stroke： | 6040Z:80mm 8060Z:105mm Engraving depth depends on the length of the tool edge | |||
Acceptable material thickness | 6040Z≤ 115mm 8060Z ≤ 120mm | |||
Rail type： | Chromeplate shaft + Linear Bearings, Surface hardening 61HRC | |||
Type of screw： | Ball screw (XZ axis 1605, Y axis 2005) | |||
Spindle motor： | HF water cooling spindle ,1500W2200W, 0-24000r/min | |||
Collet type： | 1500W:ER11 2200W:ER20,1/8"(3.175mm and 6mm) Collet | |||
Stepper motor and drive： | 60BYGH86-3.5A, Each axis independently driven | |||
Maximum operating speed： | 4000mm/min (Engraving speed: 300-3000mm/min) | |||
Repeat positioning Accuracy： | 0.03mm | |||
Software Compatability： | Mach3/Emc2/Kcam, (Type3,Wentai, ArtCAM, coppercam) | |||
Command code： | G code/.nc/.ncc/.tab/.txt | |||
Rotation Axis (4th Axis) Description: | Center height: H = 60mm Maximum turning diameter: ≤ 110mm Deceleration ratio: 4:1 Stepper motor: NEMA23BHH76-3A Weight: 5.5KG | |||
Free Gifts:
Handwheel x1(piece)
Metal bits x14pcs
Milling bits x10pcs
ER collects x2pcs
CNC Clamps x4pcs
CNC Vice x1(piece)
