Model: CNC3040
Working area: 30*40mm
Zaxis stoke: 120mm ；after install limit switch it is 100mm
Screw : ball-screw 1204
Optical axis：Diameter 16mm
Aluminum profile： 2060
Limit Switch： 6pcs , 3pin cable
Emergency stop switch： 16mm
Stepper motor: Nema23 57 stepper motor
Product Advantages：
Longer 120mm stoke for Zaxis module
Z-axis adopts customized holes, no screws are required for installation
Customized limit switch, emergency stop switch installation hole, direct installation, convenient and quick
Using ball screw, more precise, higher work efficiency
The control box design integrates the control board, power supply, limit, emergency stop and other functions into one, convenient connection
The drag chain and wire clip design is to organize all the connecting lines together, neat and orderly
Packing List:
Whole machine set*1
500W spindle*1
Control box*1
Limit Switch *6
Emergency stop switch *1
ER11 8MM chunk*1
3.175mm collet *1
3.175 drill bit *10pcs
