1.5KW/2.2KW Water Cooled Spindle Kit CNC Spindle Motor+2.2kw Inverter +65/80mm Clamp +Water Pump+13pcs ER20 for CNC Wood Router
Package Included:
1 x 2.2KWCNCWater Cooled Spindle
1 x 2.2KW VDF
1 x 3.5M Water Pump
1 x 5M Water Pipes
1 x 80mm Spindle Clamp
13 x ER20 Collet (1,2,3.175,4,5,6,7,8,9,10,11,12.7,13mm)
Note: if you buy 1.5kw spindle set, the collect is er11,thanks
Product description:
1.Spindle Motor:
Size: 80mm
Power: 2200W
Voltage: 220V
Frequency: 0-400Hz
Speed: 0-24000rpm
Water Cooling ER20 collet
Runout off: less than 0.005mm
Germany SKS 4pcs bearing
Bearing type:4pcs bearing C7005X2 C7002X2
Grease Lubrication
2.Inverter:
Input Voltage:110V/0220V(+/-15%) ,We also stock 380V(+/-15%), please contact us
Output Voltage:110V/220V AC
Input Frequency:48-63 Hz
Output Frequency:0-400 Hz
Input Phase:1 or 3 phase
Output Phase:3 phase
The parameter of the inverter is :
PD005=400
PD004=400
PD003=400
Note:If there is no problem, please do not change the parameters of the inverter.
3.ER20 Collet 1 Set:
Gripping Range: 1MM to 13MM(1,2,3.175,4,5,6,7,8,9,10,11,12.7,13mm)
4.Water Pump:
Voltage: 220V
Structure: Single-stage Pump
Pressure: High Pressure
Application: Submersible
Usage: Water
5.5M Water Pipes:
Size:5M 6mm (ID)*8mm (OD)
6.Spindle Motor Clamp Mount:
Diameter: 80mm
Material: Aluminum,Surface sandblasted
Application: Wood working industry rourter, such as wood door milling engraving and cutting, furniture producing
How to connect:
The package come with two Aviation plugs, just put the little one into the spindle, then use the large one to fix into the little one, you will see the marked number (1.2.3.4) on the top of large one, Pin 1 goes to terminal U on the vfd. Pin 2 goes to terminal V on the vfd. Pin 3 goes to terminal W on the vfd. Pin 4 is a ground/common.
