New 4 Inch LiteVNA 6.3 GHz Vector Network Analyzer Antenna Shortwave MF HF VHF Portable Digital Display Antenna Analyzer Testing
Product description:
LiteVNA is a portable vector network analyzer newly launched in November 2021, up to 6.3GHz. LiteVNA is based on the previously introduced NanoVNA and SAA2 with major improvements.
In order to minimize power consumption and size, LiteVNA uses only one mixer, multiple internal RF switches for S11 and S21 measurements, and IFFT calculations for TDR and DTF measurements.
LiteVNA took into account the opinions of the community when designing, and now in addition to a wider measurement range, it also brings a faster scanning speed and more scanning points. Combined with the easy-to-use interface consistent with NanoVNA, LiteVNA can now be easily used as a field testing tool.
LiteVNA includes a MicroSD slot, so you can save the field test data or screen to the MicroSD card at any time. The measurement range of LiteVNA is up to 6.3GHz, which can meet common amateur radio and Internet of Things applications, as well as the emerging 5GHz test, making the latest 5.8GHz wifi and 5.8GHz image transmission applications possible.
Packing list:
1. LiteVNA host*1 (including 4-inch touch screen, 2000mAh battery)
2. 30cm SMA male to male SS405 RF cable *2
3. SMA female to female connector *1
4. SMA simple calibration kit SHORT *1
5. SMA simple calibration kit OPEN *1
6. SMA simple calibration kit LOAD *1
7. USB Type-C data cable *1
8. Touch paddle
