Hot Sell Models 20W 30W 50W 60W Raycus Max JPT DAVI Fiber CO2 Laser Engraver Engraving
Marking Machine For Metal Non-metal Stuffs
(Optional Fiber lens : 150*150mm by default, if need other sizes, please let me know after placing the order 50x50mm/70x70mm/110x110mm/150x150mm/175x175mm/200x200mm/220x220mm/300x300mm )
Fiber laser marking is used for metal stuff fast marking mainly,
(it is not working for wood and leather, other material are all ok)
CO2 Metal marking machine is used for non-metal stuff fast marking mainly,
(it is not working for metal , other material are all ok )
RE: Have different case with different price, but basic functions are same.
Specification:
Brand |
LY |
Laser power |
20W/30W/50W/60W ( MAX / RAYCUS / JPT) |
WorkingArea |
200*200mm(Optional 50x50mm/70x70mm/110x110mm/150x150mm/175x175mm/200x200mm/220x220mm/300x300mm) |
Cooling Mode |
Air Cooling |
Laser Wavelength |
10.64 um |
Frequency of pulse |
20-100 KHz |
Marking Depth |
≤0.3 mm |
Marking Speed |
≤4000 mm/s RC1001 (If need SG7110 galvanometer,please contact with seller to add more $100 ) |
Marking Lines |
1-10 lines |
Minimum Line Width |
0.01 mm |
Minimum Character |
0.15 mm |
Repeatability Accuracy |
±0.002 mm |
Resolution Ratio |
0.1 mm |
Marking Content |
Text, pattern, date, bar code, etc |
Operation System |
Microsoft Windows XP or Windows 2000 WIN 7 WIN8 WIN 10 |
Control Software |
EZCAD ENGLISH Control Software |
Graphic Format Supported |
BMP, JPG, GIF, TGA, Ai, DXF, PLT, PNG, TIF, ai, DXF, DST, etc. |
Unit Power |
≤0.9 KW |
Operation Temperature |
5°C-40°C |
Relative Moisture |
≤ 90%, no fog |
Dimensions(L*W*H) |
95 x 78 x 55 cm |
Power supply requirements |
220 V or 110V |
Weight |
60KG |
Warranty |
24 months |
Specification:
Brand |
LY |
|
Power |
40W( 60W is higher US$2200) |
|
Galvanometer |
RC1001 ≤4000 mm/s (If need SG7110 galvanometer,please contact with seller to add more $100 ) |
|
Power supplier |
Mean well |
|
Laser wavelength |
1064NM |
|
Laser quality |
M2<1.4 |
|
Output frequency |
20KHZ-80KHZ |
|
Laser Marking Area |
|
|
Mini line width |
0.01mm |
|
Repetition accuracy |
0.0001mm |
|
Voltage |
220V or 110V |
|
Marking speed |
5000mm/s |
|
Cooling system |
Air-cooling |
|
Net weight |
45KG |
