Affordable Wholesale CNC 3.2kw ER20 Water cooled spindle 3.2kw updated water cooling spindle motor for CNC Router engraving machine!

In Stock

Affordable Wholesale CNC 3.2kw ER20 Water cooled spindle 3.2kw updated water cooling spindle motor for CNC Router engraving machine!

SKU: 1005001303240791

Safe Payment Guarantee:

1 & 220v 3.2kw ER20 4 bearings water cooled spindle

1 & 220v 4.0kw HUANYANG inverter/VFD

1 & 100mm spindle clamp/bracket

1 & 75w water pump & 5m water pipes

1 kit ER20 high accuracy collet (≤0.008mm) --- 4,6,8,10,12,1/2,1/4,1/8 (As gift)

There are 4 labyrinth seal in the front section of the spindle，Prevents lubricant leakage from bearings and intrusion of harmful impurities (dust, moisture, corrosive gases) and bearing seals under high-speed conditions.

Size:100x250mm(Middle body diameter:100mm;Length:250mm)
Speed Ways:Through 3-phase output inverter and adjust the inverter frequency to change the spindle speed.
Cooling:Water cooling
Power Interface:Optional H20-4 pins waterproof air plug. The air plug marked "1 ","2"," 3"," 4", "1 ","2 ","3" were connected to inverter (U, V, W), 4 connected inverter ground.
Power:3.2kw
Voltage:220v/380v
Current:15A/8A
Frequency:0-400Hz
Speed:0-24000rpm
Runout Off:Less than 0.01mm
Diameter(mm):100
Bearing Type:2 x 7005 P4 DT & 2 x 7003 P4 DT
4pcs fully sealed angular contact bearings
Collet:ER20
Clip Knifediameter:13mm,12mm,12.7mm,11mm,10mm,9mm,8mm,7mm, 6.35mm,6mm, 5mm, 4mm, 3.175mm, 3mm, 2mm, 1mm(standard 6mm)
Water Cooling ER20 collet chunk
Grease Lubrication
Main Application:Engrave for wood,bamboo,normal PCB,PVC,PMMA,plastic,bamboo,duotone board(ABS)and etc nonmetal,also can engrave on gold,silver,copper,aluminium,Pb etc soft metal surface working.

P4 fully sealed angular contact bearings ,2×7005C P4 DT &2×7003C P4 DT,increase spindle life .Longer length make the torque bigger,more powerful. Carefull assembly make the spindle more precisional.

Precision 0.01mm.Coaxial degree less than 0.0025mm Shipment within 4 days,promise the delivery time. We are the spindle manufacturer,we offer only best quality and best price to you.

Pay attention: The spindle size is 100x250mm, bigger torque.

The voice of the spindle is very low,almost no vibration.

1.Our Ceramic ball bearings spindle use4 pcs ceramic ball bearings.

2.Ceramic ball bearings are resistant tohigh temperatures and low heat, usually 3-5 degrees lower than steel ball bearings during using .

3.Ceramic ball bearings havelow friction, low noise and long service life.

4.If you want to use the spindle for aluminum, hard wood, then ceramic ball bearings better than steel ball bearings.

Inverter Type:Huanyang 220v 4.0kw

Input Voltage:220V(+/-15%)

Output Voltage:220vAC

Input Frequency:48-63 Hz

Output Frequency:0-400 Hz

Input Phase:1 or 3 phase

Output Phase:3 phase

Warranty:1 year from the date you purchased

PID control; advanced calculus PID closed-loop arithmetic, quick responding speed and high suitability;
Easy PLC function can realize 16 legs of speed and inverter control function;
RS485 communication port, adopting standard international MODBUS main circuit control;
With extremely strong anti-jamming capability
Low output ratting torque0.5HZ-150%, low speed running ability;
Carrier adjustable by 16KHZ, completely soundless working environment;
Broad voltage working area, normal running in 304V-456V;
Auto voltage regulation (AVR) technique, for ensuring the inverter load capability;
Various control technique by both synchronization and non-synchronization, dynamically realize fast starting without changing brakes;
With perfect error protection and short circuit starting protection capability;
Dead-time compensation and auto torque slip compensation function, can realize 180% high torque output at low frequency 0.25Hz;
Unique EMC design,can minimize inverter's pollution to power;
Overall reinforcement layer to suit all kinds of harsh enviroment;

DO NOT set up the inverter by yourself if you don't know how to, or it will make both the spindle and inverter burn easily.

Please contact us, we have manuals, videos and pictures to help you.

Diameter:100mm

Material:Cast Aluminium

Features

Compared with thealuminiumprofile fixture,the accuracy is much higher , and it is hard to deform.

Inner wall is very smooth, outer walls is sandblasted, relatively fine uniform, but not very smooth.

Cast aluminiumfixtureis much heavier thanaluminiumprofile fixture

Product Description

Cast aluminium fixture is high quality aluminium which is casting with a special manufacturing process ,compared with ordinary aluminium ,This product has toughness, strong shock resistance, high hardness and strong antioxidant activity.

Usage

Cast aluminium fixture is mainly used for fixation of ancillary products, thereby ensuring the verticality of balancing and ancillary products, ancillary products to improve running accuracy, reduce noise, reduce the accumulated error.

Max Head: 3.2 m;

Power: 75w;

Maximum flow:3200L / H

Plug Cord Length: 1.4m

Voltage: 220V;

Frequency: 50 HZ

Outlet size: 4 and 6 mm;

Dimensions: 125 * 105 * 90 mm

Advantage

High Lift / Large Flow Rate / Highly Durable / Excellent Insulation / Can cool the machine quickly / Good quality and long life / Large inventory / Big strong power

Features

The shell is made of high quality plastic, which is anti corrosive and high durable.
Pumps have excellent insulation thanks to the motor bearing completely sealed.
Pumps combione pumping, filtered,oxygen and fountains in one.

Note

Must be used in the water.
Must cut off the electricity once the product works improperly and must maintain it after lifting it from the water.

Type: ER20 High accuracy collet

Material:65Mn Steel

Quantity: 8 pcs(4mm,6mm,8mm,10mm,12mm,1/4(6.35mm),1/8(3.175mm),1/2(12.7mm))

Precision ≤ 0.008mm

Hardened & Precision ground

Widely used in boring, milling, drilling, CNC milling machine wire tapping,engraving spindle machines,machining centers and other processing.

Spindle working environment temperature is usually -10 ~ 40 .

Before installing the first electric spindle axis head turned by hand, should feel flexible, non-blocking phenomenon.

Spindle in the preservation and transportation, high-speed grease inside the bearing state will change, customers should be running at low speed for 30 minutes. 3000 rpm and then follow the poor increase, run 20 minutes each. Spindle and the inverter should be working together. The inverter's specifications and parameter settings need match spindles parameter.

Connect the inverter spindle, three-phase inverter power cord should be soldered in the plug 1 (U), 2 (V), 3 (W) feet, 4 feet for the ground. After the power is turned on, to observe whether the spindle rotation axis indicates the direction consistent. If inconsistency should be immediately shut down, replace the inverter and spindle connected two wires of three-phase power supply.

It should ensure that before use of water-cooled spindle, the cooling system is working properly. Every day before using the spindle must be running at low speed for 15-20 minutes. Clamping the cutters to spindle, collet nuts ,collets,cutters must be clean enough. Shank inserted into the collet must be greater than 15mm.

Water cooled spindle MUST be used with water pump. Otherwise the spindle will soon broken.
AC spindle motor MUST use with inverter. The power of inverter need equal or bigger than the spindle power. Before using,please set up the inverter parameters suitable for spindle. Otherwise the spindle and inverter will broken at once.
When you use the spindle,the noise is not same as always,please STOP the spindle at once. You may need to replace the spindle bearings.

Before shipping , we did the oil seal to avoid the rust during the long shipment. When you get the spindle, please clearing the oil seal before using. Thank you.

1. Cooling in different ways: water-cooled spindle motor is the use of the water cycle to cool the heat generated after the high-speed rotating spindle, spindle motor with fan-cooled approach to cooling.

2. Noise: Water-cooled spindle motor is basically no noise, but the air-cooled spindle motor is very loud.

3. Life aspects: Water-cooled spindle motor pay attention to maintenance, frequently changes the water or the use of industrial water coolers, air-cooled spindle fan mainly by the wind blowing the heat transferred to the heat sink, so as to achieve the cooling effect.

4.If you need use for metal ,hard wood,granite,stone,you can choose metal spindle.Metal spindle much better than wood spindle.

Spindle from the production - assembly - test, and finally the perfect packaging .

We will 100% guarantee security to the hands of the guests.

Shipping Cost

Affordable Wholesale CNC 3.2kw ER20 Water cooled spindle 3.2kw updated water cooling spindle motor for CNC Router engraving machine!

1 & 220v 3.2kw ER20 4 bearings water cooled spindle

1 & 220v 4.0kw HUANYANG inverter/VFD

1 & 100mm spindle clamp/bracket

1 & 75w water pump & 5m water pipes

1 kit ER20 high accuracy collet (≤0.008mm) --- 4,6,8,10,12,1/2,1/4,1/8 (As gift)

There are 4 labyrinth seal in the front section of the spindle，Prevents lubricant leakage from bearings and intrusion of harmful impurities (dust, moisture, corrosive gases) and bearing seals under high-speed conditions.

Size:100x250mm(Middle body diameter:100mm;Length:250mm)

Speed Ways:Through 3-phase output inverter and adjust the inverter frequency to change the spindle speed.

Cooling:Water cooling

Power Interface:Optional H20-4 pins waterproof air plug. The air plug marked "1 ","2"," 3"," 4", "1 ","2 ","3" were connected to inverter (U, V, W), 4 connected inverter ground.

Power:3.2kw

Voltage:220v/380v

Current:15A/8A

Frequency:0-400Hz

Speed:0-24000rpm

Runout Off:Less than 0.01mm

Diameter(mm):100

Bearing Type:2 x 7005 P4 DT & 2 x 7003 P4 DT

4pcs fully sealed angular contact bearings

Collet:ER20

Clip Knifediameter:13mm,12mm,12.7mm,11mm,10mm,9mm,8mm,7mm, 6.35mm,6mm, 5mm, 4mm, 3.175mm, 3mm, 2mm, 1mm(standard 6mm)

Water Cooling ER20 collet chunk

Grease Lubrication

Main Application:Engrave for wood,bamboo,normal PCB,PVC,PMMA,plastic,bamboo,duotone board(ABS)and etc nonmetal,also can engrave on gold,silver,copper,aluminium,Pb etc soft metal surface working.

P4 fully sealed angular contact bearings ,2×7005C P4 DT &2×7003C P4 DT,increase spindle life .Longer length make the torque bigger,more powerful. Carefull assembly make the spindle more precisional.

Pay attention: The spindle size is 100x250mm, bigger torque.

The voice of the spindle is very low,almost no vibration.

1.Our Ceramic ball bearings spindle use4 pcs ceramic ball bearings.

2.Ceramic ball bearings are resistant tohigh temperatures and low heat, usually 3-5 degrees lower than steel ball bearings during using .

3.Ceramic ball bearings havelow friction, low noise and long service life.

4.If you want to use the spindle for aluminum, hard wood, then ceramic ball bearings better than steel ball bearings.

Inverter Type:Huanyang 220v 4.0kw

Input Voltage:220V(+/-15%)

Output Voltage:220vAC

Input Frequency:48-63 Hz

Output Frequency:0-400 Hz

Input Phase:1 or 3 phase

Output Phase:3 phase

Warranty:1 year from the date you purchased

PID control; advanced calculus PID closed-loop arithmetic, quick responding speed and high suitability;

Easy PLC function can realize 16 legs of speed and inverter control function;

RS485 communication port, adopting standard international MODBUS main circuit control;

With extremely strong anti-jamming capability

Low output ratting torque0.5HZ-150%, low speed running ability;

Carrier adjustable by 16KHZ, completely soundless working environment;

Broad voltage working area, normal running in 304V-456V;

Auto voltage regulation (AVR) technique, for ensuring the inverter load capability;

Various control technique by both synchronization and non-synchronization, dynamically realize fast starting without changing brakes;

With perfect error protection and short circuit starting protection capability;

Dead-time compensation and auto torque slip compensation function, can realize 180% high torque output at low frequency 0.25Hz;

Unique EMC design,can minimize inverter's pollution to power;

Overall reinforcement layer to suit all kinds of harsh enviroment;

Material:Cast Aluminium

Compared with thealuminiumprofile fixture,the accuracy is much higher , and it is hard to deform.

Inner wall is very smooth, outer walls is sandblasted, relatively fine uniform, but not very smooth.

Cast aluminiumfixtureis much heavier thanaluminiumprofile fixture

Cast aluminium fixture is high quality aluminium which is casting with a special manufacturing process ,compared with ordinary aluminium ,This product has toughness, strong shock resistance, high hardness and strong antioxidant activity.

Cast aluminium fixture is mainly used for fixation of ancillary products, thereby ensuring the verticality of balancing and ancillary products, ancillary products to improve running accuracy, reduce noise, reduce the accumulated error.

Power: 75w;

Maximum flow:3200L / H

Plug Cord Length: 1.4m

Voltage: 220V;

Frequency: 50 HZ

Outlet size: 4 and 6 mm;

Dimensions: 125 * 105 * 90 mm

High Lift / Large Flow Rate / Highly Durable / Excellent Insulation / Can cool the machine quickly / Good quality and long life / Large inventory / Big strong power

The shell is made of high quality plastic, which is anti corrosive and high durable.Pumps have excellent insulation thanks to the motor bearing completely sealed.Pumps combione pumping, filtered,oxygen and fountains in one.

Must be used in the water.Must cut off the electricity once the product works improperly and must maintain it after lifting it from the water.

Type: ER20 High accuracy collet

Material:65Mn Steel

Quantity: 8 pcs(4mm,6mm,8mm,10mm,12mm,1/4(6.35mm),1/8(3.175mm),1/2(12.7mm))

Precision ≤ 0.008mm

Hardened & Precision ground

Widely used in boring, milling, drilling, CNC milling machine wire tapping,engraving spindle machines,machining centers and other processing.

Spindle working environment temperature is usually -10 ~ 40 .

Before installing the first electric spindle axis head turned by hand, should feel flexible, non-blocking phenomenon.

Water cooled spindle MUST be used with water pump. Otherwise the spindle will soon broken.

AC spindle motor MUST use with inverter. The power of inverter need equal or bigger than the spindle power. Before using,please set up the inverter parameters suitable for spindle. Otherwise the spindle and inverter will broken at once.

When you use the spindle,the noise is not same as always,please STOP the spindle at once. You may need to replace the spindle bearings.

The shell is made of high quality plastic, which is anti corrosive and high durable.
Pumps have excellent insulation thanks to the motor bearing completely sealed.
Pumps combione pumping, filtered,oxygen and fountains in one.

Must be used in the water.
Must cut off the electricity once the product works improperly and must maintain it after lifting it from the water.
