NOTE:
Caros compradores brasileiros, pagamos tarifas elevadas pelos produtos no armazém brasileiro. Se você optar por enviá-lo para o armazém brasileiro, ele será entregue em 1-5 dias úteis, obrigado!
(Como os óculos são produtos anti-epidêmicos, a alfândega brasileira não permite produtos com óculos. Os produtos no armazém do Brasil não incluem óculos, obrigado pela compreensão).
DESCRIPTION
NEJE 3 with N30820 module is a portable and safty desktop laser engraving and cutting machine with strong engraving and cutting capabilities. This device is small in size but equipped with almost all professional functions designed by NEJE. Particularly good at engraving hardwood, glass, rubber stamps, cutting materials smaller than 170x170mm, and users who require a portable design is a very good choice. NEJE 3 also has functions such as auto air assist and auto smoke extension. MEMS gyro sensor can also protect safe use.
SPECIFICATION
Model： NEJE 3Control Board: NEJE 3Satety Protection: MEMS Working Size: 170 x 170 mm Pixel: 2266 x 2266 px Dot pitch: 0.075mm 338dpiSoftware: NEJE APP for Android, NEJE 3 APP for iOS / ipadOS / macOS, NEJE Win Software, LaserGRBL，LightBurn.LightBurn ( paid software from the official website of Lightburn.) supports Windows, Mac OS, and Linux.NEJE Software OTA Upgrading Service: YES NEJE Cloud Gallery: YES NEJE Scanner function: YES Frame material: CNC Cutting Composite plate, aluminum alloy, acrylic.Input Voltage: AC100-240V, 50/60Hz Output Voltage: DC12V, 4A Laser: N30820Optical Power: 450nm 5.5W CWContinue working: Unlimited Wavelength： 450nm Beam Shape：focus 0.08x0.08mm DotDrive: Built-inLens Material: D-ZK3
3D Egraving
-3D images can be easily sculpted without adding air assist.
Rubber Stamp Engraving
- Rubber stamp engraving (requires air assist 0.4-1.5mpa)
EXPANSION DESCRIPTION
M7 relay expansion accessories, can be used to control AC or DC power supply smoke exhaust system, can also be used to control other circuits, used as M8, there are safety risks when operating high-voltage circuits, requiring professional operation; M8 valve expansion accessories, can be used To control the air compressor switch, neje 3 supports accessories expansion, but the relay module, air valve module and Door need to be purchased separately, not included in the product list.
About Air Assist
-It is only necessary to add air assist when cutting plywood larger than 3mm and engraving rubber stamps such as carbonized materials. Air assist below 0.4mpa does not make any sense.
About Roller
-Support almost all rollers, round wine bottles, mugs, ceramic mugs can be engraved.
N30610 Laser Module FEATURE
NEJE N30610 module is a high-power micro-engraving module, this module has extremely small focus and strong power, it is very suitable for high-precision micro-engraving of hardwood products and gray-scale engraving of hard materials, gray-scale engraving in ceramics and small objects Engraving is the best choice.
NEJE 3 (N30820) Package list
NEJE 3 (N30610) Package list
