CNC 3018 Plus 500W Spindle 40W Laser Head Kit 3018 Pro Engraver 15W Laser Power PCB Engraving Milling Machine Wood Router
Specifications for 3018 Pro:
Control software：GRBL control
Construction：Aluminum + plastic
Working area：300*180*40mm
Frame size：400*330*240mm
Spindle：775 spindle motor (12-36V) 24V: 7000r/min,
36V: 9000r/min
Step motor：1.3A 0.25N.m
Wire rod：T8
Power Supply：24V 5.6A （110V-240V）
Support System： Windows XP / Win 7 / Win 8/ Linux
Standard：The complete set of the parts and tools
Engraving materials ：Plastic, wood, acrylic, PVC, PCB and other soft materials
Weight: 8KG
Specifications for CNC 3018 Plus:
XYZ three-axis actual stroke 300*180*60mm
Aluminum Table Size 300*180mm
Material: Aluminum
Stepper motor: Nema17 Stepper*3
Screw: T8 stainless steel screw, lead 8MM, POM anti-backlash nut
Spindle hole diameter: 52mm
Laser module diameter:40mm
Control software: GRBL Control
Spindle: 500W Optional
Laser: 5.5W/30W/40W Optional
Power Supply: 24V 5A
Supported System: Windows XP/ Win 7/ Win 8/ Win10
