Mini Laser Infrared Riflescope Rangefinder for Hunting Shooting Distance Angle Speed Measurer Tactical Riflescope Mounted
1) Mini laser ranger.
2) All metal shell,hard enought.
3) Color OLED display.
4) The mate of rilfescope, coordinate with the machine aiming point.
5) Easy to mount on rifle, bows, crossbows and other products.
6) Can be continuous distance measurement in foggy weather.
7) Test the speed if the moving objects in the same direction.
8) Units of measurement can be change immediately.
Specification
Measurement Range: 5 - 1200m
Accuracy: +/-1m
Speed Range: 0 - 300km/h
Water Resistance: IPX4
Battery: 3V CR2 (not included)
Display: OLED screen
Wave Length: 950nm
Material: Alloy
Dimension: 8.3 * 3.9 * 5.8cm / 3.3 * 1.5 * 2.3in
Weight: 223g / 7.9oz
Description
◐ Continuous press the tail switch turns on the device.
◐ Ranging mode is the default; this is the distance measurement mode.
continuous press the M button, change the unit of distance. M and Y.
◐ Click the rat tail switch, the upward arrow will be appears at the bottom right of the screen,
◐ That's mean the device is in the ranging mode. Measurement the distance.
◐ Press M key to change the mode.
◐ Multi-level power display.
◐ In the "Speed" mode, the unit of the measured value needs to be converted separately. (Km/h or mile/h)
◐ Pitch angle data by way of real time continuous output
Ranging Mode:
☛ Fog mode
▁Fog mode screen appears, press power key ranging
▁Fog mode can handle the interference caused by fog.
☛ Horizontal distance measurement mode
▁Press power key to start measuring the distance and slope. After obtaining measurements.
▁Calculates and displays the horizontal distance and measuring slope.
☛ Fog + Horizontal distance mode
▁Press power key to start.
▁In the fog can be horizontal distance measurement.
☛ Fast lock into the target
▁Continuous measurment and real-time ranging.
☛ Speed mode
▁Press power key to start the measurement speed.
▁In the speed mode. Long press M button to switch km/h and mile/h.
1. Ranging range 5-1200 meters, ranging resolution 0.1m
2. Red Laser pointer (650nm)
3. Laser Wavelength 905 nm
4. Rat tail switch
5. Waterproof grade IP54
6. Battery CR-2 X 1 (3V) lithium battery
7. Leather rail interface standard
8. Audio Reading (Chinese/English)
9.OLED display, support the screen to follow the direction of rotation.
10. Aiming mode: mechanical aiming + scope adjustment
11. Size: 5*6.2*10cm
12. Weight:241g
Hunting Mini Range Finder
● 1200m new launch mini air gun riflescope army mountable scope day and night laser hunting rangefinder
● This device is a professional Plug-in Ranging Device. It has latest innovative functions which can offer you a good experience. Easy to mount on rifle, bows, crossbows and other products.
Mode:
Ranging mode：Meter (M) mode
Ranging mode：code (Y) mode
Horizontal distance mode：Meter (M) mode
Horizontal distance mode：code (Y) mode
Speed measurement mode：Mile/H
