Product parameter
Product parameter
Model: Split SX2-2.5-10
Maximum temperature: 1000 degrees
Internal size: 20*12*8CM
External dimensions: 60*40*40CM
Power: 2.5KW
Voltage: 220v
Weight: 50KG
Timing: 1-9999 minutes
Heating element: Fe-Cr-Al alloy resistance wire
Temperature measuring element: nickel-silicon thermocouple
Model: Split SX2-2.5-12
Maximum temperature: 1200 degrees
Internal size: 20*12*8 CM
External dimensions: 60*40*40CM
Power: 2.5KW
Voltage: 220v
Weight: 50KG
Timing: 1-9999 minutes
Heating element: Fe-Cr-Al alloy resistance wire
Temperature measuring element: platinum rhodium thermocouple
Remarks: Split type needs to install wiring
The scope of application of the muffle furnace: the resistance furnace adopts a periodic operation type, which is used for laboratories, industrial and mining enterprises, scientific research units for small steel processing, metal/ceramic sintering, dissolution analysis, etc. and high temperature heating.
Intelligent temperature control panel: accurate temperature, simple operation, with timing, self-adjustment function (you can set different temperature shorts by yourself, up to 32 shorts, after setting, this process will be automatically completed)
