Product Package
1 x DDCSV3.1 CNC Offline Controller （3/4 Axis Optional） 1 x 4 Axis MPG handwheel 1 x 4GB USB Flash Disk 1 x USB Extension Cable Accessories 1 x Mounting bracket 1 x Handwheel Hook
Product Description
DDCSV3.1 is 3 or 4 axis motion controller for stepper and servo systems. We are very proud of this product; it combines great power with a tiny footprint and is easy to use. After a very short time you will be familiar with the functions and this manual will help you. The highest output pulse per axis is 500 KHz. The pulse width is adjustable (refer to driver manual). The control period of each position is only 4 milliseconds. This provides high control precision for stepper motors and servo motors. DDCSV3.1 numerical control system adopts the ARM+FPGA design framework. ARM controls the human-computer interface and code analysis and the FPGA provides the underlying algorithms and creates the control pulse. This guarantees reliable control and easy operation. The internal operating system is Linux based. The panel layout structure of the CR8-500 is very rational to save space. All operations are controlled by only 17 keys and a comprehensive G code set is supported. DDCSV3.1 can be used for many styles and types of CNC machines. Lathes, Routers, Pick & Place and Mills are just a few examples. The CR8-500 operates as a Stand Alone system without the need of a computer. This guarantees high precision, accuracy and reliability. The interface, even very comprehensive, can be learned in a very short time. The CNC 4/6 Axis handheld controller MPG Pendant with x1, x10, x100 selectable, the MPG pendant for 4/6 axis CNC machine, it equipped with our popular machined MPG unit with 4/6axis and scale selector, LED indicator also send feedback from the CNC machine to user about the status of the unit. - All Wiring isolated from MPG unit and provide a easy to install wiring diagram, it suit both commercial machine as a replacement jog control unit or other computer based controller. Which add great control flexibility to the system
Controller performance parameters
Features:
1) American and imperial units in the system can be converted; 2) Handwheel MPG master control page, file page and configuration page, extended keyboard can also operate and edit controller; 3) New trial cut function, single line processing, 4) The tool setting function is increased to 4 modes; 5) The software is greatly adjusted and optimized, and the parameter configuration is greatly increased to make the performance more powerful and reliable; 6) Controller language is Chinese/English/Russian parameters 1) 16-channel optocoupler isolated digital input interface, 3 optocouplers isolated digital input and output; 2) The new version enhances the algorithm, supports flexible circular interpolation, and corrects the deficiencies in the circular interpolation commands in the old version; 3) 1 channel 0-10V spindle speed control analog output interface (can be modified into PWM output); 4) 3-4 axis pulse direction uses differential output, the maximum interpolation pulse output frequency is 500Khz; 5) ARM9 main control chip, FPGA core algorithm chip; 6) 5 inches TFT screen, resolution: 480x272, 17 operation keys; 7) The main control equipment is 24VDC power input, the current capacity requirement is not less than 0.5A; 8) The IO port power input is also 24VDC, and the current capacity requirement is not less than 0.5A; all IO ports do not need to be configured with an external power supply, such as Connect relays and the like; 9) Support U disk to read G command, G command file size is not required; 10) Support standard MPG; 11) Support panel button single-axis manual jog and linkage and distance operation; 12) Support fast specified operation position operation; 13) Support multi-coordinate system (automatically save power down); 14) With breakpoint memory, power-down automatic protection function; 15) Support to save the breakpoint function (automatically save by pressing the pause button during operation, automatically save after power off); 16) The controller controller only supports NPN type limit switches; 17) The new version is made of sheet metal, which is atmospheric and has better anti-interference ability.
contrller define and method
contrller size：
Handwheel performance parameters
Handwheel size：
