Hot Air Bga Rework Soldering Station HT-R490 Repairing Machine 3 Zones 2400W Solder Machine for Laptop PS4 Game Board Repair
1: head 1:Head heater limit rod. (To prevent head heater crushed PCB)
2: head heater. (Temperature zone)
3: The head heater adjust the handle up and down. (Adjustable up and down position)
4: LED lights. (Increase the brightness of the work area)
5: head heater, hot air nozzle. (Can be replaced according to different chip size)
6: Infrared heating panels warm-up area. (Third zone)
7: PCB clamping bracket. (Fixed PCB board with a holding device)
8: PCB clamping bracket locking screw. (Tighten the right side of the PCB clamping bracket)
9: The display and control buttons. (Show and set parameters)
10: the upper heater, locking handle and move around.
11: the upper part of the heater cable
12: the lower part of the heater and wind mouth. (Second temperature)
13: shaped plate fixture and tighten the screws.
14: shaped plate fixture. (Clamping irregular PCB, such as notebook panels)
15: plywood jig and move around to tighten the screws.
Technical Parameters
Basic Parameters | |
Heating | HR |
Dimension | L580mmx W560mmx H650mm |
Weight | 28kg |
Total weight | About 35 kg, vary with the differen need of the users |
Electrical Parameters | |
Power | 220V AC |
Upper Heating | HR |
Size of upper (IR) | --------------- |
Consumption of upper (IR) | --------------- |
Nozzle of upper(HR) | 4pcs: 19x19,29x29,34x34,37x37 mm |
Consumption of upper (HR) | 800W |
Bottom Heating | HR |
Nozzle of bottom(HR) | 1 pcs: 50x50 mm |
Consumption of bottom (HR) | 800W |
Bottom Preheat | IR |
Consumption of preheat (IR) | 2400W |
General power | 4KW |
Temperature Control | |
Control mode of Upper | Independent temperature control, high-precision closed-loop control, precision ± 0.5%, Alarm |
Control mode of Bottom | Independent temperature control, high-precision closed-loop control, precision ± 0.5%, NO Alarm |
Rework Function | |
SMD | Suit for welding, remove or repair packaged devices |
Size of applicable chips | ≤80mm x80 mm |
Size of applicable PCB | MIN 10mm*10mmMAX 350mm*400mm |
Packing list:
1× bga rework station
5× nozzles: 4 pcs top(19,29,34,37mm) and 1 pcs bottom(50mm);
6× pcb jig (with screw)
1x vacuum pen
1× k-type thermocouple
1x socket head wrench
1x Computer Cable
1× CD of manual and software (if not get, may be lost in customs, please contact us)
