Newly Portable NDT Digital Ultrasonic Flaw Detector YFD300 High-speed capture Automated calibration Automated gain Range 0~10000
Automated calibration、Automated gain
DAC、AVG、TCG、B scan、AWS
High-speed capture and very low noise
Solid metal housing
high contrast viewing of the waveform from bright
Powerful pc software and reports can be export to excel
· Automated display precise flaw location(Depth d、level p、distance s、amplitude、sz dB、ф); · Automated switch three staff gauge ((Depth d、level p、distance s); · Automated calibration of transducer Zero-point, Angles, Front edge and material Velocity ; · Convenient to make and use DAC\TCG and AVG to evaluate the echo, the curve can be modified and compensated · 6dB DAC functions; · 100 independence setup, any criterion can be input freely, we can work in the scene without test block; · Big memory of 1000 A graph · Automated gain and gain scan; · Peak Hold and Peak Memory; · B scan; · AWS D1.1 · Automated make video of test process and play; use upan,the length of video is unlimited. · Powerful pc software and reports can be export to excel; · Li battery, continue working time up to 10 hours; · The embeded software can be online updated; Other assistant function · Display freeze; · Automated echo degree; · Angles and K-value; · Lock and unlock function of system parameters; · Electronic clock calendar ; · Two gates setting and alarm indication; · Gate and DAC alarm; | |
Standard Configuration
Table 1.1 List of standard configurations
Designation | Quantity |
Main unit | 1 |
1.5A/9V power adaptor | 1 |
probe connecting cable | 1 |
Carrying case | 1 |
Instruction manual | 1 |
Straight probe | 4MHz 10mm (One) |
Angle probe | 8×9 60°4MHz (One) |
