Affordable Wholesale Cnc Router for Metal Wood with 40w Laser, 3 axis 4040 Cnc Router Machine for Carving Cut MDF Aluminum PCB Laser Engraver FoxAlie

SKU: 1005004148964055
Safe Payment Guarantee:
You May Be Wondering

1. How is the quality?

100% satisfied, click for more customer reviews on FoxAlien Masuter.


2. Is there a warranty?

All FoxAlien CNC machines are protected by official 1-year warranty since the date of delivery.

Tips: There are 6400+ FoxAlien cnc router owners and fanciers in our Facebook group. Click to Join FoxAlien CNC Router & Laser Machine Group. All your questions will be answered in there.


3. Do I have to pay for tax?

We have warehouses in the US and Europe, so if you choose to ship from Europe and the US, you won't have to pay customs duties. This shipping always takes about 3-7 days.

Please Note ! ! ! ! ! If you do not choose overseas warehouse delivery. Please make sure your address is correct and complete before payment! We usually ship your order within 48 hours using AliExpress Standard Shipping, it usually takes around 15-30 days to ship, duties may apply. Please understand that customs duties are not under our control, if you are in doubt about this, please consult your local customs.


4. it comes with laser madule?

Yes, it comes with 40W FoxAlien laser modules. Compatible with all FoxAlien laser modules.

TIP: Click to see FoxAlien 40w Laser from Youtube.


5. Can this CNC machine cut/engrave metals like Zinc Brass Aluminum?

Yes, it can be done with the correct parameters and router bits. Recommended for use with 300W Spindle Upgrade Kit.

TIP: Click to see FoxAlien Masuter 300w spindle Upgrade from Youtube.


6. Can this CNC machine cut/engrave all kinds of material such as wood, leather, MDF, acrylic, foam, resin, nylon, carbon fiber, PCB ?

Yes it can. TIP: Click to see FoxAlien CNC machine Masuter engraving from Youtube.


7. What software does this work with? and include the software?

This CNC machine is based on GRBL and is compatible with GRBL control software. We provide free open source software - Candle, which can also be downloaded online / if you need other software, you may need to buy it yourself.


8. Can I run this directly connected to my PC?

Yes, this CNC machine can be connected to PC through USB cable.


9. Do I have to load cad software to do 3D engraving?

This machine moves on all 3 axes (x, y, and z) simultaneously, what we call true 3-axis CNC in the industry. It cannot 3D sculpt and is not compatible with Mach3 software. But it can do relief.


10. Can the Masuter power supply and frame handle a spindle over 300w? Maybe like a 500w or 600w spindle?

Yes, the Masuter supports that. Actually high power spindle needs to be powered by independent power supply. You may need to find the suitable power supply for 500w spindle by yourself. In this case, the original power supply comes with the machine is used to drive the motors.


Specification


Active Working Area: 15.75” x 14.96” x 2.16” (400 x 380 x 55mm)

Spindle: 775; 10000RPM

Input Supply: 12V/5A

Step Motor: 1.3 A, 12V, 0.25 Nm torque (2.2 in lb)

Supported OS: Windows XP/7/8/10, MAC OS, Linux


Package List

● 1x Masuter CNC Router (main parts pre-assembled)
● 1x Control Board
● 1x 60W Spindle
● 2x MDF working table
● 10x Engraving Bits
● 4x Hold-down Clamps
● 1x Power Supply
● 1x USB cable
● 1x Z Probe
● Packs of screws and tools

● 40W Laser Module Kit

Main Features:

● Masuter 4040 is a cost-effective CNC router with large working area of 400 x 380 x 55mm (15.75” x 14.96” x 2.16”). It uses a 60W spindle and NEMA17 stepper motors. Max moving speed is 2000mm/min and spindle speed range is 0~10000.

● The control board is equipped with an upgraded 32-bit chip which works more efficient and stable. It also supports add-ons such as offline controller, 300W spindle and power modules. (Add-ons sold separately)

● HOME function and Emergency-Stop button are integrated on the machine. The machine will go to home with simply press the button.

● Masuter 4040 is capable to engrave, cut and drill many kinds of material such as wood, MDF, acrylic, foam, resin, nylon, PCB, and aluminum etc.

● Main parts are pre-assembled. It takes about 20-30mins to fully assembly. The machine is compatible with Grbl software. It supports Windows XP/7/10, Linux and Mac OS.
