ATT : AC220v is ok,but need use inverter for output,can`t use household electricity directly
Material :spindle cover is 304 stainless steel,water jet is high pressure casting aluminum pipe,copper coil
Power connection
GX16 waterproof aviation plug,(1/2/3)connect inverter(U/V/W)in turn,4 connect inverter earth wire
Packing list
1pcs*spindle ,1pcs*aviation ,1pcs*ER nut , 1pcs*ER colletSpecification
Model | GDZ-85-2.2 |
Rev(rpm) | 24000 |
Power(kw) | 2.2KW |
Voltage(V) | 220V(380V also in stock) |
Current(A) | 8 |
Frequency(HZ) | 400 |
Cool type | water cooling |
Diameter(mm) | 85 |
Lubricate | Grease |
Bearing | 7005C P4*2 7003C P4*2 |
Collet(mm) | ER20 (standard size:6mm diameter) |
CNC tool | 1-13(mm) |
Repair time | Bearing(one year), spindle(one year) |
Size | 85mm |
Collet(mm) | ER20 (standard size 6mm diameter) |
