Affordable Wholesale STAR TRIP 2" Geared dual-speed focusing mount Suitable for SCT RC reflector and other telescopes(Can install ZWO EAF)

SKU: 1005004691935398
Safe Payment Guarantee:

This product is in stock and can be purchased directly!



Product Details


The 2-inch toothed focusing seat adopts the form of bearing + rack. The bearing is designed to be adjustable and can be adjusted to a higher accuracy. The 8 bearings are evenly distributed and the force is applied in all directions. The rack is only responsible for transmission. Because the force changes the feel and produces displacement, this is also the big feature of this focusing mount; in addition, the interface is adjusted to a 75mm V port, which can realize the CAA function, and it is more convenient to connect the adapter ring (such as the SCT interface) ); In terms of size, the net height is 40mm, and there are two versions with 35mm/60mm stroke. SCT only supports 35mm stroke; the body weight is close to 700g, equipped with high-precision two-speed fine-tuning, and the fine-tuning teeth can be used for timing belts.


Regarding the use of CAA, since the focusing is a 2-inch interface, you can use the M48CAA to connect the 2-inch socket first and then install it in the focusing base to fix it. If you use the MPCC, you can directly install the M48CAA on the MPCC.


Precautions:


1. Cinda interface is divided into convex and round, please distinguish (see if there is a gap in the base).


2. SCT telescopes such as Star Tronschka can only use 35mm stroke.


3. The RC interface is suitable for RC telescopes such as GSO.


4. Provide a dedicated interface for EAF ESC, buy it as a gift for focusing! (But also place an order at the same time) Single shots will not be shipped.


5. Do not use too long screws when installing the ESC in the screw hole of the focusing wheel on the right side of the focusing, otherwise it may cause the fine adjustment to fail!


There are two types of adapters for Newtonian reflecting telescopes


1.Suitable for SCT


2.Newtonian reflecting telescope (round)


3. Newtonian reflecting telescope (round with convex)


4.Suitable for RC telescope


The picture of the SCT I used after installation

The use effect is great, it is very beautiful!!
