1 pc -- 4th Axis 100mm 3 Jaw Chuck ( Positive jaw and counter jaw )
1 pc -- Tailstock
4th Axis: 100mm 3 Jaw
Stepper Motor:
Nema23 57x56mm
Shaft Diameter: 6.35 mm
Shaft length: 25.5mm
Step Angle:1.8
Current: 3A
Voltage: 2.85V
Temperature Rise :80 c max
Ambient Temperature:-20 c--+50 c
Phase No. : 2HP
Insulation Resistance: 100MOhm(500V DC)
Holding Torque: 9.0kg.cm
Chuck type:
100MM three jaw self-centering chuck
Center Height 65mm
Total height, 115MM
Angle, 0.036 degree/step
Reduction ratio:50:1 (synchronous deceleration mode)
Magnetic stepping motor: Two-phase 57 step motor Four-wire
Tip: We have 50:1 reduction gearbox and 100:1 reduction gearbox.
If you need 100:1 reduction gearbox,please tell us!!
Fourth axis pulse equivalent settings:
The Mach3 system settings: the pulses for 1 required:
( the motor 1 Circle of pulse number × the drive of subdivision number × reduction ratio) ÷ 360 degrees
For example, the two-phase 57 motor, the ubdivision number 16, the reduction ratio 50:1
(200 × 16 × 50) ÷ 360 = 444.44444444)
Ncstudio system settings: the angle of a pulse walking:
360 ÷ (the motor 1 Circle of pulse numberr × × the drive of subdivision number × reduction ratio)
For example: the two-phase 57 motor, the breakdown of the number 16, reduction ratio 50:1
360 ÷ (200 × 16 × 50) = 0.00225
X or Y axis instead of the algorithm is:
Circumference ÷ (the motor 1 Circle of pulse numberr × × the drive of subdivision number × reduction ratio)
Engraving different sizes of round bars, equivalent needs to be set
Tailstock type:
Center Height: 65mm
Stretch distance:50mm
Axial locking wrench for tailstock
