SF-HC25G Plasma THC Arc Voltage Height Controller With THC Lifter JYKB-100 For Plasma Cutting Machine Height Adjuster NEWCARVE

Introduction of SF-HC25G:

The SF-HC25G Plasma Torch Height Controller is a torch height automatic control module specifically designed for portable plasma cutting machines.

The SF-HC25G plasma torch height controller is easy to operate, easy to debug, affordable, and fully digitally controlled for reliable performance. It is an ideal accessory product for welding and cutting equipment manufacturers. The main unit and panel split structure make it ideal for portable cutting machines.

Important statement of SF-HC25G

• There may be some differences between the physical and manual contents of the SF-HC25G plasma torch height controller.

• Please refer to the actual product. This product or its accessories are subject to change without notice. To check for updates.Be sure to read the safety warnings and precautions to avoid accidents caused by improper use.

• Before using this product, you must strictly follow the detailed instructions in this system manual to ensure proper use of the product.

• Regarding the contents of the SF-HC25G plasma torch height controller and this manual, if any specific illegal use is carried out, it does not represent the position of the company and refuses to recognize its legal responsibility. All consequences are borne by the user.

• Safety warnings are used to prevent injury to humans and property.

• In the process of using the SF-HC25G torch height controller, if any product quality problems occur, consumers can call the company's product service center or authorized offices, distributors, agents to obtain the corresponding product services.

• No part of this material may be reproduced, reproduced, or used without express written permission, and the offender shall be solely responsible for the damage caused. In order to operate the product safely and achieve the design control accuracy of the product and avoid damage to it, carefully read the warnings described below, and strictly observe them.

• The installer must be a relevant industry or a technician with relevant experience.

• you must read this manual carefully before installation.

• Verify that the selected power supply matches the specifications you require.

• Do not install or plug or unplug the plug while it is powered on.

• Install the location as far as possible from the heat source.

• The controller enclosure must be well grounded to prevent electric shock or affect the operation of the controller.

• The steel to be cut must be well-grounded and kept in good connection with the controller casing to ensure the accuracy of the height control.

• Please handle it carefully. Do not collide or vibrate strongly to avoid damage to the product.

•  Do not disassemble the torch height controller or change its internal structure to prevent accidents or malfunctions.

Technical characteristics of SF-HC25G

The SF-HC25G plasma torch height controller is based on years of practice and several generations of related products.

• This product uses 32-bit arm as the core, two sets of 3-digit digital tube display, digital control. The linear adjustment device is not included inside, which greatly improves stability.

• The speed parameters can be modified and can be modified arbitrarily according to the power supply and lifting mechanism.

• The circuit adopts the chip technology, there is no adjustable device inside, and the full digital control technology ensures the high reliability of the product.

• Simple operation, two sets of digital tubes display the set arc pressure, and the actual arc voltage respectively, which is simple and intuitive. There are 3 knobs for setting parameter operations.

• Easy to control interface, suitable for all plasma cutting CNC systems, can also be used alone.

• Adopt the proximity positioning mode of the proximity switch.

• PWM output, 255 speed adjustable, precise control of motor speed, multi-speed current setting, short circuit protection.

• The anti-collision function of the cutting tool. When the cutting nozzle touches the steel plate, the controller will quickly lift the cutting tool a certain distance to effectively protect the cutting nozzle.

• All input and output are optoisolated. Plasma voltage feedback adopts a linear optoisolator and independent isolated power supply. It is very compatible with imported plasma power supplies of various brands with its own voltage divider.

• Integrated arc start success judgment function, arc starts success feedback function.

• Main Specifications

• Power requirements: DC24V±10%3 A/50Hz

• Applicable motor: 24V DC brush motor

• Drive mode: PWM

• Output current: <power input current

• Initial positioning mode: proximity switch or mechanical switch (normally open normally closed through jumper cap setting)

• Maximum control accuracy: ±1V

• Box size: host 145X90X42mm panel 120X55X40mm

• Working environment temperature: -10 ~ 60 ° C

• Detection system: isolated arc voltage divider (B2 version)

Adjust the controller details as follows:

• SF-HC25G height adjuster

• display panel

• partial pressure plate

• Display communication line

• User's Guide One (Chinese)

• Weight (including the box): 0.7 kg;

SF-HC25G arc voltage height controller has no special port.

Four wires are required from the voltage divider of the SF-HC25G height adjuster and the plasma power connection. The two wires are at the port where the plasma starts to arc, and the plasma cutter will have it. The arc voltage signal is two lines divided into positive and negative poles. If the plasma power supply does not have a dedicated port, the plasma power supply housing needs to be opened and connected from the secondary rectification inside the plasma power supply, which is the original arc voltage of the plasma power supply.

You only need to connect the ground wire because the interference from the plasma power supply is too large. The ground wire needs to use a copper rod with a diameter of 50mm or two angle steels with a length of 2 meters. Go underground. Connect to the housing of the plasma power supply.

Application of JYKB-100-DC24V:

Portable/desktop light-duty CNC flame/plasma cutting machine.

Description of JYKB-100-DC24V:
1. This flame/plasma cutting machine Z-axis torch lifter is driven by DC gear motor to lift the torch up & down
2. The most important part of the device, which is to keep the machine's cutting accuracy and to support plasma arc positioning function, is equipped with NPN proximity switches
3. This lifter's mechanical movement part is made of Taiwan TBI ball screw, standard linear shaft(SFC) & linear slider on the ends; torch clamper/holder is made of bearing steel, and fastened by linear sliders, which is to ensure the lifter movement's stability & verticality
4. Convenient to install, work simple, improving the work efficiency

Air control plug definition of JYKB-100-DC24V:
1 foot --D +; (motor positive)
2 feet --D -; (motor negative)
3 feet --Zero; (positioning normally open output)
4 feet --COM; (positioning normally open output)
Note: Built-in limit (reverse diode)

Parameter of JYKB-100-DC24V:
1. T-304 stainless steel screw
2. Includes jig (torch range 12mm-38mm)
3. Lift inside a plasma arc positioning
4. Aluminum body, the upper and lower aluminum sheet thickness of 8mm, forming a processing center
5. Four-core plug
6. Colour: black spray housing
7. Working stroke: 100mm
8. Working voltage: DC24V
9. Bearing weight: 3 kg
10. Dimensions: length 320 * W 80 * H 60
11. Mounting Hole Size Length: center distance between two holes 40mm
