Package include:
1) 1set GRBL 3018 CNC Laser machine kit ( without ER11 Collet and laser Head )
2) 1set GRB L 3018 CNC Laser machine kit (without laser) + ER11-A type nut with Collet
3) 1set GRB L 3018 CNC Laser machine kit (without laser) + ER11-A type nut with Collet and MPG controller
4) 1set GRB L 3018 CNC Laser machine kit ( with 500mw laser head, only lase shipping from China )
5) 1set GRB L 3018 CNC Laser machine kit ( with 2500mw laser head,only lase shipping from China )
6) 1set GRB L 3018 CNC Laser machine kit ( with 5500mw laser head,only lase shipping from China )
10 x 20°0.1mm drill bits4 x plates1 Set of allen wrench1 x power supply Notice: This item from EU warehouse delivery to EU customer, but Becase Laser is dangerous product,without our EU warehouse stock, if you order 3018 CNC machine with any laser head,we can only from China ship to you
Introduction:
Body used profiles and plastic, small size, light weight, USB interface, GRBL control system, learning, entry preferred. Can use carving knife, but also can use laser engraving.
Can be engraved plastic, wood, acrylic, pvc, pcb, wood and the like material.
Specification:
Working area : 30x18x4.5cm
Frame size : 40x33x24cm
Spindle : 775 spindle motor (12-36V)24V: 10000r/min
Spindle Chuck: normal
Step motor : Fuselage length 34MM,Current 1.33A, 12v.Torque 0.25N/M
Power supply : 24V 5.6A
Software : GRBL controller
Support System: Windows XP / Win 7 / Linux
Drill bits: tip 0.1mm ,20 degree , diameter3.175mm.the package include 10p
Laser: 500mw 405nm,12v / 2500mw 450nm,12v / 5500mw 450nm,12v.
I. GRBL 0.9J,USB port cnc engraving machine control board, 3 axis control
Specification:
Connection: USB (USB-CH340)
Software: GRBL controller, UniversalGcodeSender
Input voltage: 12-36V
Master chip: atmel 328P (arduino nano)
Stepper motor driver: A4988
Spindle drive chip: MOSFET (recommendation 12~36V, current : within 10A )
Spindle PWM speed: Support
Support stepper motor: 12V, maximum current of 2A or less is recommended within 1.5A and additional heat. (Any stepper motor 42, 57)
Laser engraving: Support
Power Interface: 5.5-2.5mm DC interface
Main application:
Can be engraved plastic, wood, acrylic, pvc, pcb, wood and the like material.
SD shows it is SD card condition, turn on power supply after insert SD card, otherwise, it won't work. SD card capacity 4G could be recognized.
Press X- or X+ button to switchControl：Press confirmation button to access manually controlling pageFile：Press confirmation button to access file pageSet：Press confirmation button to access setting page
On the off-line controller, buttons control corresponding actions.
SPN is spindle controlling,should press SPIN. Fan is fan controlling, should press SMOD.Note: To exit this page, should press back button longly. after exit, save the current location as engraving starting point X0Y0Z0
Note: system can recognize max 100 available files one time (***.TXT***.txt***. NC***.nc***.CNC
***.cnc***.TAP***.tap could be recognized)，not support files with long name.Press Y+ or Y- to choose files need to be engraved, press confirmation button to access engraving page.
Press ok to start engraving
If you want to stop during engraving, press back button longly, then back to the file selection page（machine will not stop at once, as GRBL controller has already saved a part of G code, will stop after carry out completely).
